Bio-Argo match-ups

Author: Eli Holmes (NOAA)
Last updated: November 21, 2025

We have upwards of 33k bbp700 and 10k chl-a points for the global bio-Argo data. The goal is to get the Rrs data, all bands, for each of these. However, with so many points we need to be careful with memory. Just opening the meta-data for all the Rrs files, 500+ days since March 2024, will eat up a lot of memory.

What do we do?

1. When we open the PACE Rrs files, we create ds with chunks{} so that dask knows the chunk structure and will not try to load the whole file.
2. We compute the vector of indices for the Argo points and use ds.vindex([vector_i, vector_j). That will load only the needed chunks.
3. We work through the files in batches rather than one massive for loop. This will keep the memory from exploding on us as we open files.

Load the Argo profile data

This is the lat/lon/time data for every profile we have from Mar 2024 to Nov 2025. We will use this information to find matching Rrs, Kd, and chlor_a data from PACE.

# Load data from GitHub
df_y_name="CHLA"; df_lat_name="LATITUDE"; df_lon_name="LONGITUDE"; df_time_name="TIME"
import pandas as pd
base_url="https://raw.githubusercontent.com/fish-pace/2025-tutorials/main/data/argo_monthly_nc/"
url = f"{base_url}argo_profiles_index.parquet"
argo_chl_df = pd.read_parquet(url)
len(argo_chl_df)

15792

Load custom functions

# --- Custom python functions ---
import os, importlib
# Looks to see if you have the file already and if not, downloads from GitHub
if not os.path.exists("ml_utils.py"):
    !wget -q https://raw.githubusercontent.com/fish-pace/2025-tutorials/main/ml_utils.py

import ml_utils as mu
importlib.reload(mu)

<module 'ml_utils' from '/home/jovyan/2025-tutorials/ml_utils.py'>

Workflow to process one PACE file

Assume:

• The files are for a regular grid, i.e. level 3 data
• The files do not have a time coordinate. This is how the PACE level 3 daily and 8-day files are currently structured.
• We are looking at a variable, like Rrs, that has a 3rd dimension of wavelength or similar. Usually called wavelength or wavelength_3d. So the dims are (lat, lon, 3rd dim)
• time_coverage_start and time_coverage_end exist as attributes in the files.
• ds[ds_vec_name] is a 1D coordinate aligned with the last dimension of ds_var_name.

Process Steps:

1. Subset our Argo dataframe to only those rows within in the time window covered by the cloud-hosted xarray dataset (ds). Let’s call that df_day
2. Get the lat/lon indices of ds that correspond to the lat/lon rows in df_day. These indices will look like [0, 3, 6] and [0, 10, 15] corresponding to index pairs, like (3, 10) corresponding to the lat/lon pair in a row of df_day.
3. Do a fast point retrieval from ds. ds is cloud optimized (chunked) file and we only want to the chunks that we need. We do not need to load all the chunks. I/O of cloud-hosted data is the slow part so don’t touch more of the data than you need to.
4. Build a dataframe with the predictor variables that we want from ds.

## The function to process one file is in ml_utils.py
help(mu.one_file_matches)

Help on function one_file_matches in module ml_utils:

one_file_matches(f: 'earthaccess.store.EarthAccessFile', df: pandas.core.frame.DataFrame, ds_lat_name: str = 'lat', ds_lon_name: str = 'lon', ds_time_name: str = 'time', ds_vec_name: Optional[str] = 'wavelength', ds_var_name: str = 'Rrs', ds_vec_sel=None, df_lat_name: str = 'lat', df_lon_name: str = 'lon', df_time_name: str = 'time') -> Tuple[Optional[pandas.core.frame.DataFrame], Optional[pandas.core.frame.DataFrame]]
        Match Argo point observations to a single PACE L2/L3 file and extract
        colocated satellite values and metadata.

        Parameters
        ----------
        f : file-like object
            An earthaccess/open file-like handle for a single PACE granule
            (as returned by `earthaccess.open`). This object is passed directly
            to `xr.open_dataset` to read the granule.
        df : pandas.DataFrame
            A DataFrame containing Argo observations. Must include columns for
            time, latitude, longitude, and the target Argo variable to be matched.

        ds_lat_name, ds_lon_name, ds_time_name : str, optional
            Names of the latitude, longitude, and time variables in the PACE
            dataset. Default: "lat", "lon", "time".

        ds_vec_name : str or None, optional
            Name of the spectral dimension in the PACE dataset (e.g. "wavelength").
            If not None, matched satellite spectra are returned with one column per
            wavelength. If None, only a single variable is extracted.

        ds_vec_sel : value or None, optional
            Value of the spectral dimension in the PACE dataset (e.g. "wavelength")
            to select. If None, matched satellite spectra are returned with one column per
            wavelength. If given, only a single variable is extracted for that value.

        ds_var_name : str, optional
            Name of the satellite variable to extract from the PACE dataset
            (e.g. "Rrs" or "chlor_a").

        df_lat_name, df_lon_name, df_time_name : str, optional
            Column names in `df` for latitude, longitude, and time.

        df_var_name : str, optional
            Column name in `df` for the Argo variable being matched.

        Returns
        -------
        df_record : pandas.DataFrame or None
            A subset of `df` containing only the Argo observations whose timestamps
            fall within the PACE file's temporal coverage window. Returns None if
            no observations fall within this window.

        pts : pandas.DataFrame or None
            A DataFrame containing colocated satellite values for each matched Argo
            observation, including:
                - matched PACE pixel coordinates
                - the Argo variable value
                - spectral satellite values (if `ds_vec_name` is provided)
                - PACE temporal metadata (`pace_t_start`, `pace_t_end`)
                - the PACE file name (`pace_file`)
            Returns None if no points were matched.

    Examples
        --------
        >>> import earthaccess
        >>> import pandas as pd
        >>>
        >>> # Log in and search for PACE granules (simplified example)
        >>> earthaccess.login()
        >>> results = earthaccess.search(
        ...     short_name="PACE_OCI_L3M_DAY_IOP",
        ...     temporal=("2024-03-05", "2024-03-06"),
        ...     bounding_box=(-180, -90, 180, 90),
        ... )
        >>> files = earthaccess.open(results, pqdm_kwargs={"disable": True})
        >>>
        >>> # Load Argo matchup candidates
        >>> df_argo = pd.read_parquet("tutorial_data/chl_argo_points.parquet")
        >>>
        >>> # Match a single PACE file to the Argo DataFrame
        >>> df_record, pts = one_file_matches(
        ...     files[0],
        ...     df_argo,
        ...     ds_vec_name=None,            # e.g. non-spectral variable like "chlor_a"
        ...     ds_var_name="chlor_a",
        ...     df_var_name="argo_chl"
        ... )

        Notes
        -----
        - Time matching uses a half-open interval: `[t_start, t_end)`.
        - Spatial matching is performed using nearest-neighbor lookup on the PACE
          latitude/longitude grid.
        - This function does not load full PACE granules into memory; only metadata
          and the required pixel values are accessed.
        - Returned DataFrames are aligned row-by-row: each row in `pts` corresponds
          to the same row in `df_record`.

Run through the PACE files in batches

Just in case something hangs.

Workflow

• Create a function to get all matches for one PACE file one_file_matches()
• Create a function to run a batch of PACE files run_batch()
• Do a for loop over our batches and run run_batch() on each
• Gather results into one file

We will run for all PACE files that we have. Later when we match to the Argo profiles, we can choose the best PACE data, e.g. only use NRT data if that is all that is available.

run_batch() function

• Run mu.one_file_matches() on each file
• Save results from the batch to a file in case the process crashes
• Later we will reconstruct from the batch files. The files are small.

%%time
from datetime import datetime

def run_batch(
    results, df,
    ds_vec_name="wavelength", ds_var_name="Rrs", ds_vec_sel=None,
    df_time_name="TIME", df_lat_name="LATITUDE", df_lon_name="LONGITUDE"
):
    """
    Run a batch of PACE files (results) and return PACE variables for lat/lon/time rows in a
    dataframe.

    Parameters
    ----------
    results : earthaccess results object as returned by `earthaccess.search`).

    df : A pandas DataFrame containing Argo observations. Must include columns for
        time, latitude, longitude.

    ds_vec_name : str or None, optional
        Name of the spectral dimension in the PACE dataset (e.g. "wavelength").
        If not None, matched satellite spectra are returned with one column per
        wavelength. If None, only a single variable is extracted.

    ds_vec_sel : value or None, optional
        Value of the spectral dimension in the PACE dataset (e.g. "wavelength")
        to select. If None, matched satellite spectra are returned with one column per
        wavelength. If given, only a single variable is extracted for that value.

    ds_var_name : str, optional
        Name of the variable to extract from the PACE dataset
        (e.g. "Rrs" or "chlor_a").

    df_lat_name, df_lon_name, df_time_name : str, optional
        Column names in `df` for latitude, longitude, and time.
    """

    # Make sure to refresh fileset to minimize the chance that the token expires before we are done
    # this for loop consumes about 6Gb of RAM
    fileset = earthaccess.open(results, pqdm_kwargs={"disable": True} );

    df_plus = []
    for i, f in enumerate(fileset):
        df_record, pts = mu.one_file_matches(
            f, df,
            ds_vec_name=ds_vec_name, ds_var_name=ds_var_name, ds_vec_sel=ds_vec_sel,
            df_time_name=df_time_name, df_lat_name=df_lat_name, df_lon_name=df_lon_name)
        if df_record is None or len(df_record) == 0:
            print(f"Skipped day {i} no data in df")
            continue
        # error check
        if len(df_record) != len(pts):
            raise ValueError(f"Row mismatch: df_record={len(df_record)}, pts={len(pts)}")

        # left "concat": keep df_record rows, add pts columns by position
        df_record_plus = pd.concat(
            [
                df_record.reset_index(drop=True),
                pts.reset_index(drop=True),
            ], axis=1,)
        df_plus.append(df_record_plus)
    if not len(df_plus) == 0:
        df_plus = pd.concat(df_plus, ignore_index=True)
    return df_plus

CPU times: user 12 μs, sys: 1e+03 ns, total: 13 μs
Wall time: 16.5 μs

Get the Rrs Level 3 PACE Data

import earthaccess
auth = earthaccess.login()
# are we authenticated?
if not auth.authenticated:
    # ask for credentials and persist them in a .netrc file
    auth.login(strategy="interactive", persist=True)
import xarray as xr
df = argo_chl_df
rrs_results = earthaccess.search_data(
    short_name = "PACE_OCI_L3M_RRS",
    temporal = (df.TIME.min(), df.TIME.max()),
    granule_name="*.DAY.*.4km.*"
)
rrs_results_nrt = earthaccess.search_data(
    short_name = "PACE_OCI_L3M_RRS_NRT",
    temporal = (df.TIME.min(), df.TIME.max()),
    granule_name="*.DAY.*.4km.*"
)
results = rrs_results + rrs_results_nrt
print(f"{len(results)} days of PACE data")

712 days of PACE data

Check the format of individuals day data.

import xarray as xr
fileset = earthaccess.open(results[0:1], pqdm_kwargs={"disable": True} )
ds = xr.open_dataset(
        fileset[0],
        chunks={}
    )
ds

<xarray.Dataset> Size: 26GB
Dimensions:     (lat: 4320, lon: 8640, wavelength: 172, rgb: 3,
                 eightbitcolor: 256)
Coordinates:
  * wavelength  (wavelength) float64 1kB 346.0 348.0 351.0 ... 714.0 717.0 719.0
  * lat         (lat) float32 17kB 89.98 89.94 89.9 ... -89.9 -89.94 -89.98
  * lon         (lon) float32 35kB -180.0 -179.9 -179.9 ... 179.9 179.9 180.0
Dimensions without coordinates: rgb, eightbitcolor
Data variables:
    Rrs         (lat, lon, wavelength) float32 26GB dask.array<chunksize=(16, 1024, 8), meta=np.ndarray>
    palette     (rgb, eightbitcolor) uint8 768B dask.array<chunksize=(3, 256), meta=np.ndarray>
Attributes: (12/64)
    product_name:                      PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs...
    instrument:                        OCI
    title:                             OCI Level-3 Standard Mapped Image
    project:                           Ocean Biology Processing Group (NASA/G...
    platform:                          PACE
    source:                            satellite observations from OCI-PACE
    ...                                ...
    identifier_product_doi:            10.5067/PACE/OCI/L3M/RRS/3.1
    keywords:                          Earth Science > Oceans > Ocean Optics ...
    keywords_vocabulary:               NASA Global Change Master Directory (G...
    data_bins:                         3861548
    data_minimum:                      -0.009998
    data_maximum:                      0.092371605

xarray.Dataset

• Dimensions:
  • lat: 4320
  • lon: 8640
  • wavelength: 172
  • rgb: 3
  • eightbitcolor: 256
• Coordinates: (3)
  • wavelength
    (wavelength)
    float64
    346.0 348.0 351.0 ... 717.0 719.0

    long_name :

    wavelengths

    units :

    nm

    valid_min :

    0

    valid_max :

    20000

    array([346., 348., 351., 353., 356., 358., 361., 363., 366., 368., 371., 373.,
           375., 378., 380., 383., 385., 388., 390., 393., 395., 398., 400., 403.,
           405., 408., 410., 413., 415., 418., 420., 422., 425., 427., 430., 432.,
           435., 437., 440., 442., 445., 447., 450., 452., 455., 457., 460., 462.,
           465., 467., 470., 472., 475., 477., 480., 482., 485., 487., 490., 492.,
           495., 497., 500., 502., 505., 507., 510., 512., 515., 517., 520., 522.,
           525., 527., 530., 532., 535., 537., 540., 542., 545., 547., 550., 553.,
           555., 558., 560., 563., 565., 568., 570., 573., 575., 578., 580., 583.,
           586., 588., 613., 615., 618., 620., 623., 625., 627., 630., 632., 635.,
           637., 640., 641., 642., 643., 645., 646., 647., 648., 650., 651., 652.,
           653., 655., 656., 657., 658., 660., 661., 662., 663., 665., 666., 667.,
           668., 670., 671., 672., 673., 675., 676., 677., 678., 679., 681., 682.,
           683., 684., 686., 687., 688., 689., 691., 692., 693., 694., 696., 697.,
           698., 699., 701., 702., 703., 704., 706., 707., 708., 709., 711., 712.,
           713., 714., 717., 719.])

  • lat
    (lat)
    float32
    89.98 89.94 89.9 ... -89.94 -89.98

    long_name :

    Latitude

    units :

    degrees_north

    standard_name :

    latitude

    valid_min :

    -90.0

    valid_max :

    90.0

    array([ 89.979164,  89.9375  ,  89.895836, ..., -89.895836, -89.93751 ,
           -89.97917 ], shape=(4320,), dtype=float32)

  • lon
    (lon)
    float32
    -180.0 -179.9 ... 179.9 180.0

    long_name :

    Longitude

    units :

    degrees_east

    standard_name :

    longitude

    valid_min :

    -180.0

    valid_max :

    180.0

    array([-179.97917, -179.9375 , -179.89583, ...,  179.89584,  179.93752,
            179.97917], shape=(8640,), dtype=float32)

• Data variables: (2)
  • Rrs
    (lat, lon, wavelength)
    float32
    dask.array<chunksize=(16, 1024, 8), meta=np.ndarray>

    long_name :

    Remote sensing reflectance

    units :

    sr^-1

    standard_name :

    surface_ratio_of_upwelling_radiance_emerging_from_sea_water_to_downwelling_radiative_flux_in_air

    valid_min :

    -30000

    valid_max :

    25000

    display_scale :

    linear

    display_min :

    0.0

    display_max :

    0.025

    Array Chunk Bytes 23.92 GiB 512.00 kiB Shape (4320, 8640, 172) (16, 1024, 8) Dask graph 53460 chunks in 2 graph layers Data type float32 numpy.ndarray

  • palette
    (rgb, eightbitcolor)
    uint8
    dask.array<chunksize=(3, 256), meta=np.ndarray>

    Array Chunk Bytes 768 B 768 B Shape (3, 256) (3, 256) Dask graph 1 chunks in 2 graph layers Data type uint8 numpy.ndarray

• Indexes: (3)
  • wavelength
    PandasIndex

    PandasIndex(Index([346.0, 348.0, 351.0, 353.0, 356.0, 358.0, 361.0, 363.0, 366.0, 368.0,
           ...
           706.0, 707.0, 708.0, 709.0, 711.0, 712.0, 713.0, 714.0, 717.0, 719.0],
          dtype='float64', name='wavelength', length=172))

  • lat
    PandasIndex

    PandasIndex(Index([ 89.97916412353516,            89.9375,  89.89583587646484,
            89.85416412353516,            89.8125,  89.77083587646484,
            89.72916412353516,            89.6875,  89.64583587646484,
            89.60416412353516,
           ...
           -89.60417175292969, -89.64583587646484, -89.68750762939453,
           -89.72917175292969, -89.77083587646484, -89.81250762939453,
           -89.85417175292969, -89.89583587646484, -89.93750762939453,
           -89.97917175292969],
          dtype='float32', name='lat', length=4320))

  • lon
    PandasIndex

    PandasIndex(Index([-179.9791717529297,          -179.9375, -179.8958282470703,
           -179.8541717529297,          -179.8125, -179.7708282470703,
           -179.7291717529297,          -179.6875, -179.6458282470703,
           -179.6041717529297,
           ...
            179.6041717529297, 179.64584350585938, 179.68751525878906,
            179.7291717529297, 179.77084350585938, 179.81251525878906,
            179.8541717529297, 179.89584350585938, 179.93751525878906,
            179.9791717529297],
          dtype='float32', name='lon', length=8640))

• Attributes: (64)

  product_name :

  PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc

  instrument :

  OCI

  title :

  OCI Level-3 Standard Mapped Image

  project :

  Ocean Biology Processing Group (NASA/GSFC/OBPG)

  platform :

  PACE

  source :

  satellite observations from OCI-PACE

  temporal_range :

  day

  processing_version :

  3.1

  date_created :

  2025-09-21T06:00:45.000Z

  history :

  l3mapgen par=PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc.param

  l2_flag_names :

  ATMFAIL,LAND,HILT,HISATZEN,STRAYLIGHT,CLDICE,COCCOLITH,LOWLW,CHLWARN,CHLFAIL,NAVWARN,MAXAERITER,HISOLZEN,NAVFAIL,FILTER,HIGLINT

  time_coverage_start :

  2024-03-05T00:08:58.225Z

  time_coverage_end :

  2024-03-06T02:07:24.895Z

  start_orbit_number :

  0

  end_orbit_number :

  0

  map_projection :

  Equidistant Cylindrical

  latitude_units :

  degrees_north

  longitude_units :

  degrees_east

  northernmost_latitude :

  90.0

  southernmost_latitude :

  -90.0

  westernmost_longitude :

  -180.0

  easternmost_longitude :

  180.0

  geospatial_lat_max :

  90.0

  geospatial_lat_min :

  -90.0

  geospatial_lon_max :

  180.0

  geospatial_lon_min :

  -180.0

  latitude_step :

  0.041666668

  longitude_step :

  0.041666668

  sw_point_latitude :

  -89.979164

  sw_point_longitude :

  -179.97917

  spatialResolution :

  4.638312 km

  geospatial_lon_resolution :

  4.638312 km

  geospatial_lat_resolution :

  4.638312 km

  geospatial_lat_units :

  degrees_north

  geospatial_lon_units :

  degrees_east

  number_of_lines :

  4320

  number_of_columns :

  8640

  measure :

  Mean

  suggested_image_scaling_minimum :

  0.0

  suggested_image_scaling_maximum :

  0.025

  suggested_image_scaling_type :

  LINEAR

  suggested_image_scaling_applied :

  No

  _lastModified :

  2025-09-21T06:00:45.000Z

  Conventions :

  CF-1.6 ACDD-1.3

  institution :

  NASA Goddard Space Flight Center, Ocean Ecology Laboratory, Ocean Biology Processing Group

  standard_name_vocabulary :

  CF Standard Name Table v36

  naming_authority :

  gov.nasa.gsfc.sci.oceandata

  id :

  3.1/L3/PACE_OCI.20240305.L3b.DAY.RRS.V3_1.nc

  license :

  https://science.nasa.gov/earth-science/earth-science-data/data-information-policy/

  creator_name :

  NASA/GSFC/OBPG

  publisher_name :

  NASA/GSFC/OBPG

  creator_email :

  data@oceancolor.gsfc.nasa.gov

  publisher_email :

  data@oceancolor.gsfc.nasa.gov

  creator_url :

  https://oceandata.sci.gsfc.nasa.gov

  publisher_url :

  https://oceandata.sci.gsfc.nasa.gov

  processing_level :

  L3 Mapped

  cdm_data_type :

  grid

  identifier_product_doi_authority :

  http://dx.doi.org

  identifier_product_doi :

  10.5067/PACE/OCI/L3M/RRS/3.1

  keywords :

  Earth Science > Oceans > Ocean Optics > Reflectance

  keywords_vocabulary :

  NASA Global Change Master Directory (GCMD) Science Keywords

  data_bins :

  3861548

  data_minimum :

  -0.009998

  data_maximum :

  0.092371605

%%time
# test that run_batch() works
df = argo_chl_df
res=run_batch(results[0:1], df)
res.head()

CPU times: user 1.37 s, sys: 143 ms, total: 1.51 s
Wall time: 3.35 s

	profile_id	PLATFORM_NUMBER	CYCLE_NUMBER	TIME	LATITUDE	LONGITUDE	pace_Rrs_file	pace_Rrs_t_start	pace_Rrs_t_end	pace_Rrs_lat	...	pace_Rrs_706	pace_Rrs_707	pace_Rrs_708	pace_Rrs_709	pace_Rrs_711	pace_Rrs_712	pace_Rrs_713	pace_Rrs_714	pace_Rrs_717	pace_Rrs_719
0	4903485_0033	4903485	33	2024-03-05 01:16:05.000000000	29.082600	-17.213600	PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	29.062498	...	0.000218	0.000218	0.000224	0.000214	0.000214	0.000196	0.000174	0.000166	0.00016	0.000214
1	2902882_0077	2902882	77	2024-03-05 02:08:10.000000000	25.111515	148.146488	PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	25.104164	...	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN
2	5906304_0116	5906304	116	2024-03-05 06:58:45.000999936	-34.152200	-165.736500	PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	-34.145836	...	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN
3	2903856_0019	2903856	19	2024-03-05 08:16:05.000999936	0.673300	-165.453300	PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	0.687497	...	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN
4	7901028_0055	7901028	55	2024-03-05 11:32:39.019000064	69.673916	4.204859	PACE_OCI.20240305.L3m.DAY.RRS.V3_1.Rrs.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	69.687500	...	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN	NaN

5 rows × 183 columns

Run through all the files by batches

This takes about 4 hours for Rrs.

from pathlib import Path
from datetime import datetime
import pandas as pd

results_dir = Path("_temp_data/matchups")
results_dir.mkdir(exist_ok=True)

all_batches = []
batch_size = 10
var = "CHLA"
results = results
df = argo_chl_df
ds_var = "Rrs"

for batch_idx, i in enumerate(range(0, len(results), batch_size), start=1):
    batch = results[i:i+batch_size]
    print(f"Batch {batch_idx}: {len(batch)} files: {datetime.now():%H:%M:%S}")

    # If this batch was already done, skip it
    batch_path = results_dir / f"{var}_matchups_{ds_var}_batch_{batch_idx:03d}.parquet"
    if batch_path.exists():
        print(f"  -> Skipping batch {batch_idx}, found {batch_path}")
        continue

    df_batch = run_batch(batch, df)  # returns a DataFrame

    # Save this batch immediately
    df_batch.to_parquet(batch_path, index=False)
    print(f"  -> Saved {len(df_batch)} rows to {batch_path}")

Batch 1: 10 files: 03:12:40
  -> Saved 164 rows to data/matchups/CHLA_matchups_Rrs_batch_001.parquet
Batch 2: 10 files: 03:14:14
  -> Saved 175 rows to data/matchups/CHLA_matchups_Rrs_batch_002.parquet
Batch 3: 10 files: 03:15:52
  -> Saved 190 rows to data/matchups/CHLA_matchups_Rrs_batch_003.parquet
Batch 4: 10 files: 03:17:35
  -> Saved 187 rows to data/matchups/CHLA_matchups_Rrs_batch_004.parquet
Batch 5: 10 files: 03:19:25
  -> Saved 187 rows to data/matchups/CHLA_matchups_Rrs_batch_005.parquet
Batch 6: 10 files: 03:21:18
  -> Saved 176 rows to data/matchups/CHLA_matchups_Rrs_batch_006.parquet
Batch 7: 10 files: 03:23:05
  -> Saved 183 rows to data/matchups/CHLA_matchups_Rrs_batch_007.parquet
Batch 8: 10 files: 03:24:46
  -> Saved 206 rows to data/matchups/CHLA_matchups_Rrs_batch_008.parquet
Batch 9: 10 files: 03:26:31
  -> Saved 206 rows to data/matchups/CHLA_matchups_Rrs_batch_009.parquet
Batch 10: 10 files: 03:28:05
  -> Saved 196 rows to data/matchups/CHLA_matchups_Rrs_batch_010.parquet
Batch 11: 10 files: 03:29:38
  -> Saved 204 rows to data/matchups/CHLA_matchups_Rrs_batch_011.parquet
Batch 12: 10 files: 03:31:28
  -> Saved 224 rows to data/matchups/CHLA_matchups_Rrs_batch_012.parquet
Batch 13: 10 files: 03:33:17
  -> Saved 218 rows to data/matchups/CHLA_matchups_Rrs_batch_013.parquet
Batch 14: 10 files: 03:35:07
  -> Saved 206 rows to data/matchups/CHLA_matchups_Rrs_batch_014.parquet
Batch 15: 10 files: 03:36:35
  -> Saved 233 rows to data/matchups/CHLA_matchups_Rrs_batch_015.parquet
Batch 16: 10 files: 03:38:21
  -> Saved 224 rows to data/matchups/CHLA_matchups_Rrs_batch_016.parquet
Batch 17: 10 files: 03:39:53
  -> Saved 216 rows to data/matchups/CHLA_matchups_Rrs_batch_017.parquet
Batch 18: 10 files: 03:41:17
  -> Saved 244 rows to data/matchups/CHLA_matchups_Rrs_batch_018.parquet
Batch 19: 10 files: 03:42:46
  -> Saved 231 rows to data/matchups/CHLA_matchups_Rrs_batch_019.parquet
Batch 20: 10 files: 03:44:17
  -> Saved 204 rows to data/matchups/CHLA_matchups_Rrs_batch_020.parquet
Batch 21: 10 files: 03:45:44
  -> Saved 227 rows to data/matchups/CHLA_matchups_Rrs_batch_021.parquet
Batch 22: 10 files: 03:47:19
  -> Saved 231 rows to data/matchups/CHLA_matchups_Rrs_batch_022.parquet
Batch 23: 10 files: 03:48:34
  -> Saved 226 rows to data/matchups/CHLA_matchups_Rrs_batch_023.parquet
Batch 24: 10 files: 03:50:00
  -> Saved 217 rows to data/matchups/CHLA_matchups_Rrs_batch_024.parquet
Batch 25: 10 files: 03:51:23
  -> Saved 214 rows to data/matchups/CHLA_matchups_Rrs_batch_025.parquet
Batch 26: 10 files: 03:52:49
  -> Saved 232 rows to data/matchups/CHLA_matchups_Rrs_batch_026.parquet
Batch 27: 10 files: 03:54:09
  -> Saved 218 rows to data/matchups/CHLA_matchups_Rrs_batch_027.parquet
Batch 28: 10 files: 03:55:16
  -> Saved 254 rows to data/matchups/CHLA_matchups_Rrs_batch_028.parquet
Batch 29: 10 files: 03:56:42
  -> Saved 259 rows to data/matchups/CHLA_matchups_Rrs_batch_029.parquet
Batch 30: 10 files: 03:58:09
  -> Saved 240 rows to data/matchups/CHLA_matchups_Rrs_batch_030.parquet
Batch 31: 10 files: 03:59:32
  -> Saved 249 rows to data/matchups/CHLA_matchups_Rrs_batch_031.parquet
Batch 32: 10 files: 04:01:08
  -> Saved 255 rows to data/matchups/CHLA_matchups_Rrs_batch_032.parquet
Batch 33: 10 files: 04:02:50
  -> Saved 265 rows to data/matchups/CHLA_matchups_Rrs_batch_033.parquet
Batch 34: 10 files: 04:04:42
  -> Saved 273 rows to data/matchups/CHLA_matchups_Rrs_batch_034.parquet
Batch 35: 10 files: 04:06:42
  -> Saved 281 rows to data/matchups/CHLA_matchups_Rrs_batch_035.parquet
Batch 36: 10 files: 04:08:30
  -> Saved 277 rows to data/matchups/CHLA_matchups_Rrs_batch_036.parquet
Batch 37: 10 files: 04:10:44
  -> Saved 265 rows to data/matchups/CHLA_matchups_Rrs_batch_037.parquet
Batch 38: 10 files: 04:12:40
  -> Saved 262 rows to data/matchups/CHLA_matchups_Rrs_batch_038.parquet
Batch 39: 10 files: 04:14:24
  -> Saved 247 rows to data/matchups/CHLA_matchups_Rrs_batch_039.parquet
Batch 40: 10 files: 04:16:05
  -> Saved 294 rows to data/matchups/CHLA_matchups_Rrs_batch_040.parquet
Batch 41: 10 files: 04:18:00
  -> Saved 296 rows to data/matchups/CHLA_matchups_Rrs_batch_041.parquet
Batch 42: 10 files: 04:19:55
  -> Saved 290 rows to data/matchups/CHLA_matchups_Rrs_batch_042.parquet
Batch 43: 10 files: 04:21:36
  -> Saved 295 rows to data/matchups/CHLA_matchups_Rrs_batch_043.parquet
Batch 44: 10 files: 04:23:28
  -> Saved 267 rows to data/matchups/CHLA_matchups_Rrs_batch_044.parquet
Batch 45: 10 files: 04:25:14
  -> Saved 274 rows to data/matchups/CHLA_matchups_Rrs_batch_045.parquet
Batch 46: 10 files: 04:26:59
  -> Saved 281 rows to data/matchups/CHLA_matchups_Rrs_batch_046.parquet
Batch 47: 10 files: 04:28:22
  -> Saved 279 rows to data/matchups/CHLA_matchups_Rrs_batch_047.parquet
Batch 48: 10 files: 04:30:05
  -> Saved 249 rows to data/matchups/CHLA_matchups_Rrs_batch_048.parquet
Batch 49: 10 files: 04:31:50
  -> Saved 281 rows to data/matchups/CHLA_matchups_Rrs_batch_049.parquet
Batch 50: 10 files: 04:33:56
  -> Saved 296 rows to data/matchups/CHLA_matchups_Rrs_batch_050.parquet
Batch 51: 10 files: 04:36:05
  -> Saved 293 rows to data/matchups/CHLA_matchups_Rrs_batch_051.parquet
Batch 52: 10 files: 04:38:06
  -> Saved 319 rows to data/matchups/CHLA_matchups_Rrs_batch_052.parquet
Batch 53: 10 files: 04:40:22
  -> Saved 303 rows to data/matchups/CHLA_matchups_Rrs_batch_053.parquet
Batch 54: 10 files: 04:42:28
  -> Saved 309 rows to data/matchups/CHLA_matchups_Rrs_batch_054.parquet
Batch 55: 10 files: 04:44:39
  -> Saved 313 rows to data/matchups/CHLA_matchups_Rrs_batch_055.parquet
Batch 56: 10 files: 04:46:37
  -> Saved 294 rows to data/matchups/CHLA_matchups_Rrs_batch_056.parquet
Batch 57: 10 files: 04:48:35
  -> Saved 247 rows to data/matchups/CHLA_matchups_Rrs_batch_057.parquet
Batch 58: 10 files: 04:50:07
  -> Saved 282 rows to data/matchups/CHLA_matchups_Rrs_batch_058.parquet
Batch 59: 10 files: 04:52:13
  -> Saved 290 rows to data/matchups/CHLA_matchups_Rrs_batch_059.parquet
Batch 60: 10 files: 04:54:07
  -> Saved 298 rows to data/matchups/CHLA_matchups_Rrs_batch_060.parquet
Batch 61: 10 files: 04:56:01
  -> Saved 318 rows to data/matchups/CHLA_matchups_Rrs_batch_061.parquet
Batch 62: 10 files: 04:58:15
  -> Saved 300 rows to data/matchups/CHLA_matchups_Rrs_batch_062.parquet
Batch 63: 10 files: 05:00:18
  -> Saved 306 rows to data/matchups/CHLA_matchups_Rrs_batch_063.parquet
Batch 64: 10 files: 05:02:39
  -> Saved 312 rows to data/matchups/CHLA_matchups_Rrs_batch_064.parquet
Batch 65: 10 files: 05:04:44
  -> Saved 299 rows to data/matchups/CHLA_matchups_Rrs_batch_065.parquet
Batch 66: 10 files: 05:07:00
  -> Saved 294 rows to data/matchups/CHLA_matchups_Rrs_batch_066.parquet
Batch 67: 10 files: 05:09:02
  -> Saved 329 rows to data/matchups/CHLA_matchups_Rrs_batch_067.parquet
Batch 68: 10 files: 05:11:12
  -> Saved 294 rows to data/matchups/CHLA_matchups_Rrs_batch_068.parquet
Batch 69: 10 files: 05:13:14
  -> Saved 275 rows to data/matchups/CHLA_matchups_Rrs_batch_069.parquet
Batch 70: 10 files: 05:14:57
  -> Saved 277 rows to data/matchups/CHLA_matchups_Rrs_batch_070.parquet
Batch 71: 10 files: 05:16:52
  -> Saved 264 rows to data/matchups/CHLA_matchups_Rrs_batch_071.parquet
Batch 72: 2 files: 05:18:34
  -> Saved 35 rows to data/matchups/CHLA_matchups_Rrs_batch_072.parquet

# When everything is done, you can merge all batches:
from pathlib import Path
import pandas as pd

results_dir = Path("_temp_data/matchups")
var = "CHLA"
ds_var = "Rrs"

batch_files = sorted(results_dir.glob(f"{var}_matchups_{ds_var}_batch_*.parquet"))
dfs = [pd.read_parquet(f) for f in batch_files]
df_all = pd.concat(dfs, ignore_index=True)
df_all.to_parquet(f"{results_dir}/{var}_argo_{ds_var}_all.parquet", index=False)

print(f"Total rows: {len(df_all)}")

Total rows: 18119

Same idea for PACE CHLA data

# --- Custom python functions ---
import os, importlib
# Looks to see if you have the file already and if not, downloads from GitHub
if not os.path.exists("ml_utils.py"):
    !wget -q https://raw.githubusercontent.com/fish-pace/2025-tutorials/main/ml_utils.py

import ml_utils as mu
importlib.reload(mu)

<module 'ml_utils' from '/home/jovyan/2025-tutorials/ml_utils.py'>

# Add on chla to the clean parquet
import pandas as pd
import earthaccess
import xarray as xr

# Get PACE CHL data
import earthaccess
auth = earthaccess.login()
# are we authenticated?
if not auth.authenticated:
    # ask for credentials and persist them in a .netrc file
    auth.login(strategy="interactive", persist=True)
import xarray as xr
chl_results = earthaccess.search_data(
    short_name = "PACE_OCI_L3M_CHL",
    temporal = (argo_chl_df.TIME.min(), argo_chl_df.TIME.max()),
    granule_name="*.DAY.*.4km.*"
)
chl_results_nrt = earthaccess.search_data(
    short_name = "PACE_OCI_L3M_CHL_NRT",
    temporal = (argo_chl_df.TIME.min(), argo_chl_df.TIME.max()),
    granule_name="*.DAY.*.4km.*"
)
results = chl_results + chl_results_nrt
print(f"{len(results)} days of PACE data")

712 days of PACE data

%%time
# test that it works
res = run_batch(results[0:1], argo_chl_df, ds_vec_name=None, ds_var_name="chlor_a")
res.head()

CPU times: user 1.39 s, sys: 240 ms, total: 1.63 s
Wall time: 7.29 s

	profile_id	PLATFORM_NUMBER	CYCLE_NUMBER	TIME	LATITUDE	LONGITUDE	pace_chlor_a_file	pace_chlor_a_t_start	pace_chlor_a_t_end	pace_chlor_a_lat	pace_chlor_a_lon	pace_chlor_a
0	4903485_0033	4903485	33	2024-03-05 01:16:05.000000000	29.082600	-17.213600	PACE_OCI.20240305.L3m.DAY.CHL.V3_1.chlor_a.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	29.062498	-17.229162	0.265202
1	2902882_0077	2902882	77	2024-03-05 02:08:10.000000000	25.111515	148.146488	PACE_OCI.20240305.L3m.DAY.CHL.V3_1.chlor_a.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	25.104164	148.145844	NaN
2	5906304_0116	5906304	116	2024-03-05 06:58:45.000999936	-34.152200	-165.736500	PACE_OCI.20240305.L3m.DAY.CHL.V3_1.chlor_a.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	-34.145836	-165.729172	NaN
3	2903856_0019	2903856	19	2024-03-05 08:16:05.000999936	0.673300	-165.453300	PACE_OCI.20240305.L3m.DAY.CHL.V3_1.chlor_a.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	0.687497	-165.437500	NaN
4	7901028_0055	7901028	55	2024-03-05 11:32:39.019000064	69.673916	4.204859	PACE_OCI.20240305.L3m.DAY.CHL.V3_1.chlor_a.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	69.687500	4.187506	NaN

from pathlib import Path
from datetime import datetime
import pandas as pd

results_dir = Path("_temp_data/matchups")
results_dir.mkdir(exist_ok=True)

all_batches = []
batch_size = 10
var = "CHLA"
results = results
df = argo_chl_df
ds_var = "chlor_a"

for batch_idx, i in enumerate(range(0, len(results), batch_size), start=1):
    batch = results[i:i+batch_size]
    print(f"Batch {batch_idx}: {len(batch)} files: {datetime.now():%H:%M:%S}")

    # If this batch was already done, skip it
    batch_path = results_dir / f"{var}_matchups_{ds_var}_batch_{batch_idx:03d}.parquet"
    if batch_path.exists():
        print(f"  -> Skipping batch {batch_idx}, found {batch_path}")
        continue

    df_batch = run_batch(batch, df, ds_vec_name=None, ds_var_name="chlor_a")

    # Save this batch immediately
    df_batch.to_parquet(batch_path, index=False)
    print(f"  -> Saved {len(df_batch)} rows to {batch_path}")

Batch 1: 10 files: 16:01:45
  -> Saved 164 rows to data/matchups/CHLA_matchups_chlor_a_batch_001.parquet
Batch 2: 10 files: 16:01:50
  -> Saved 175 rows to data/matchups/CHLA_matchups_chlor_a_batch_002.parquet
Batch 3: 10 files: 16:01:56
  -> Saved 190 rows to data/matchups/CHLA_matchups_chlor_a_batch_003.parquet
Batch 4: 10 files: 16:02:01
  -> Saved 187 rows to data/matchups/CHLA_matchups_chlor_a_batch_004.parquet
Batch 5: 10 files: 16:02:06
  -> Saved 187 rows to data/matchups/CHLA_matchups_chlor_a_batch_005.parquet
Batch 6: 10 files: 16:02:12
  -> Saved 176 rows to data/matchups/CHLA_matchups_chlor_a_batch_006.parquet
Batch 7: 10 files: 16:02:17
  -> Saved 183 rows to data/matchups/CHLA_matchups_chlor_a_batch_007.parquet
Batch 8: 10 files: 16:02:22
  -> Saved 206 rows to data/matchups/CHLA_matchups_chlor_a_batch_008.parquet
Batch 9: 10 files: 16:02:28
  -> Saved 206 rows to data/matchups/CHLA_matchups_chlor_a_batch_009.parquet
Batch 10: 10 files: 16:02:33
  -> Saved 196 rows to data/matchups/CHLA_matchups_chlor_a_batch_010.parquet
Batch 11: 10 files: 16:02:38
  -> Saved 204 rows to data/matchups/CHLA_matchups_chlor_a_batch_011.parquet
Batch 12: 10 files: 16:02:43
  -> Saved 224 rows to data/matchups/CHLA_matchups_chlor_a_batch_012.parquet
Batch 13: 10 files: 16:02:49
  -> Saved 218 rows to data/matchups/CHLA_matchups_chlor_a_batch_013.parquet
Batch 14: 10 files: 16:02:55
  -> Saved 206 rows to data/matchups/CHLA_matchups_chlor_a_batch_014.parquet
Batch 15: 10 files: 16:03:00
  -> Saved 233 rows to data/matchups/CHLA_matchups_chlor_a_batch_015.parquet
Batch 16: 10 files: 16:03:06
  -> Saved 224 rows to data/matchups/CHLA_matchups_chlor_a_batch_016.parquet
Batch 17: 10 files: 16:03:12
  -> Saved 216 rows to data/matchups/CHLA_matchups_chlor_a_batch_017.parquet
Batch 18: 10 files: 16:03:17
  -> Saved 244 rows to data/matchups/CHLA_matchups_chlor_a_batch_018.parquet
Batch 19: 10 files: 16:03:23
  -> Saved 231 rows to data/matchups/CHLA_matchups_chlor_a_batch_019.parquet
Batch 20: 10 files: 16:03:29
  -> Saved 204 rows to data/matchups/CHLA_matchups_chlor_a_batch_020.parquet
Batch 21: 10 files: 16:03:35
  -> Saved 227 rows to data/matchups/CHLA_matchups_chlor_a_batch_021.parquet
Batch 22: 10 files: 16:03:41
  -> Saved 231 rows to data/matchups/CHLA_matchups_chlor_a_batch_022.parquet
Batch 23: 10 files: 16:03:47
  -> Saved 226 rows to data/matchups/CHLA_matchups_chlor_a_batch_023.parquet
Batch 24: 10 files: 16:03:52
  -> Saved 217 rows to data/matchups/CHLA_matchups_chlor_a_batch_024.parquet
Batch 25: 10 files: 16:03:58
  -> Saved 214 rows to data/matchups/CHLA_matchups_chlor_a_batch_025.parquet
Batch 26: 10 files: 16:04:04
  -> Saved 232 rows to data/matchups/CHLA_matchups_chlor_a_batch_026.parquet
Batch 27: 10 files: 16:04:10
  -> Saved 218 rows to data/matchups/CHLA_matchups_chlor_a_batch_027.parquet
Batch 28: 10 files: 16:04:15
  -> Saved 254 rows to data/matchups/CHLA_matchups_chlor_a_batch_028.parquet
Batch 29: 10 files: 16:04:20
  -> Saved 259 rows to data/matchups/CHLA_matchups_chlor_a_batch_029.parquet
Batch 30: 10 files: 16:04:26
  -> Saved 240 rows to data/matchups/CHLA_matchups_chlor_a_batch_030.parquet
Batch 31: 10 files: 16:04:31
  -> Saved 249 rows to data/matchups/CHLA_matchups_chlor_a_batch_031.parquet
Batch 32: 10 files: 16:04:37
  -> Saved 255 rows to data/matchups/CHLA_matchups_chlor_a_batch_032.parquet
Batch 33: 10 files: 16:04:43
  -> Saved 265 rows to data/matchups/CHLA_matchups_chlor_a_batch_033.parquet
Batch 34: 10 files: 16:04:50
  -> Saved 273 rows to data/matchups/CHLA_matchups_chlor_a_batch_034.parquet
Batch 35: 10 files: 16:04:56
  -> Saved 281 rows to data/matchups/CHLA_matchups_chlor_a_batch_035.parquet
Batch 36: 10 files: 16:05:03
  -> Saved 277 rows to data/matchups/CHLA_matchups_chlor_a_batch_036.parquet
Batch 37: 10 files: 16:05:09
  -> Saved 265 rows to data/matchups/CHLA_matchups_chlor_a_batch_037.parquet
Batch 38: 10 files: 16:05:15
  -> Saved 262 rows to data/matchups/CHLA_matchups_chlor_a_batch_038.parquet
Batch 39: 10 files: 16:05:22
  -> Saved 247 rows to data/matchups/CHLA_matchups_chlor_a_batch_039.parquet
Batch 40: 10 files: 16:05:28
  -> Saved 294 rows to data/matchups/CHLA_matchups_chlor_a_batch_040.parquet
Batch 41: 10 files: 16:05:34
  -> Saved 296 rows to data/matchups/CHLA_matchups_chlor_a_batch_041.parquet
Batch 42: 10 files: 16:05:41
  -> Saved 290 rows to data/matchups/CHLA_matchups_chlor_a_batch_042.parquet
Batch 43: 10 files: 16:05:47
  -> Saved 295 rows to data/matchups/CHLA_matchups_chlor_a_batch_043.parquet
Batch 44: 10 files: 16:05:53
  -> Saved 267 rows to data/matchups/CHLA_matchups_chlor_a_batch_044.parquet
Batch 45: 10 files: 16:05:59
  -> Saved 274 rows to data/matchups/CHLA_matchups_chlor_a_batch_045.parquet
Batch 46: 10 files: 16:06:04
  -> Saved 281 rows to data/matchups/CHLA_matchups_chlor_a_batch_046.parquet
Batch 47: 10 files: 16:06:10
  -> Saved 279 rows to data/matchups/CHLA_matchups_chlor_a_batch_047.parquet
Batch 48: 10 files: 16:06:16
  -> Saved 249 rows to data/matchups/CHLA_matchups_chlor_a_batch_048.parquet
Batch 49: 10 files: 16:06:22
  -> Saved 281 rows to data/matchups/CHLA_matchups_chlor_a_batch_049.parquet
Batch 50: 10 files: 16:06:29
  -> Saved 296 rows to data/matchups/CHLA_matchups_chlor_a_batch_050.parquet
Batch 51: 10 files: 16:06:35
  -> Saved 293 rows to data/matchups/CHLA_matchups_chlor_a_batch_051.parquet
Batch 52: 10 files: 16:06:42
  -> Saved 319 rows to data/matchups/CHLA_matchups_chlor_a_batch_052.parquet
Batch 53: 10 files: 16:06:49
  -> Saved 303 rows to data/matchups/CHLA_matchups_chlor_a_batch_053.parquet
Batch 54: 10 files: 16:06:55
  -> Saved 309 rows to data/matchups/CHLA_matchups_chlor_a_batch_054.parquet
Batch 55: 10 files: 16:07:02
  -> Saved 313 rows to data/matchups/CHLA_matchups_chlor_a_batch_055.parquet
Batch 56: 10 files: 16:07:09
  -> Saved 294 rows to data/matchups/CHLA_matchups_chlor_a_batch_056.parquet
Batch 57: 10 files: 16:07:15
  -> Saved 247 rows to data/matchups/CHLA_matchups_chlor_a_batch_057.parquet
Batch 58: 10 files: 16:07:21
  -> Saved 282 rows to data/matchups/CHLA_matchups_chlor_a_batch_058.parquet
Batch 59: 10 files: 16:07:27
  -> Saved 290 rows to data/matchups/CHLA_matchups_chlor_a_batch_059.parquet
Batch 60: 10 files: 16:07:34
  -> Saved 298 rows to data/matchups/CHLA_matchups_chlor_a_batch_060.parquet
Batch 61: 10 files: 16:07:40
  -> Saved 318 rows to data/matchups/CHLA_matchups_chlor_a_batch_061.parquet
Batch 62: 10 files: 16:07:46
  -> Saved 300 rows to data/matchups/CHLA_matchups_chlor_a_batch_062.parquet
Batch 63: 10 files: 16:07:52
  -> Saved 306 rows to data/matchups/CHLA_matchups_chlor_a_batch_063.parquet
Batch 64: 10 files: 16:07:59
  -> Saved 312 rows to data/matchups/CHLA_matchups_chlor_a_batch_064.parquet
Batch 65: 10 files: 16:08:05
  -> Saved 299 rows to data/matchups/CHLA_matchups_chlor_a_batch_065.parquet
Batch 66: 10 files: 16:08:12
  -> Saved 294 rows to data/matchups/CHLA_matchups_chlor_a_batch_066.parquet
Batch 67: 10 files: 16:08:18
  -> Saved 329 rows to data/matchups/CHLA_matchups_chlor_a_batch_067.parquet
Batch 68: 10 files: 16:08:25
  -> Saved 294 rows to data/matchups/CHLA_matchups_chlor_a_batch_068.parquet
Batch 69: 10 files: 16:08:30
  -> Saved 275 rows to data/matchups/CHLA_matchups_chlor_a_batch_069.parquet
Batch 70: 10 files: 16:08:37
  -> Saved 277 rows to data/matchups/CHLA_matchups_chlor_a_batch_070.parquet
Batch 71: 10 files: 16:08:42
  -> Saved 264 rows to data/matchups/CHLA_matchups_chlor_a_batch_071.parquet
Batch 72: 2 files: 16:08:48
  -> Saved 35 rows to data/matchups/CHLA_matchups_chlor_a_batch_072.parquet

# When everything is done, you can merge all batches:
from pathlib import Path
import pandas as pd

results_dir = Path("_temp_data/matchups")
var = "CHLA"
ds_var = "chlor_a"

batch_files = sorted(results_dir.glob(f"{var}_matchups_{ds_var}_batch_*.parquet"))
dfs = [pd.read_parquet(f) for f in batch_files]
df_all = pd.concat(dfs, ignore_index=True)
df_all.to_parquet(f"{results_dir}/{var}_argo_{ds_var}_all.parquet", index=False)

Same idea with the PACE Kd490 data

# Add on chla to the clean parquet
import pandas as pd
import earthaccess
import xarray as xr

# Get PACE CHL data
import earthaccess
auth = earthaccess.login()
# are we authenticated?
if not auth.authenticated:
    # ask for credentials and persist them in a .netrc file
    auth.login(strategy="interactive", persist=True)
import xarray as xr
kd_results = earthaccess.search_data(
    short_name = "PACE_OCI_L3M_KD",
    temporal = (argo_chl_df.TIME.min(), argo_chl_df.TIME.max()),
    granule_name="*.DAY.*.4km.*"
)
kd_results_nrt = earthaccess.search_data(
    short_name = "PACE_OCI_L3M_KD_NRT",
    temporal = (argo_chl_df.TIME.min(), argo_chl_df.TIME.max()),
    granule_name="*.DAY.*.4km.*"
)
results = kd_results + kd_results_nrt
print(f"{len(results)} days of PACE data")

712 days of PACE data

%%time
# test that it works
res = run_batch(results[0:1], argo_chl_df, ds_var_name="Kd", ds_vec_sel=490.0)
res.head()

CPU times: user 466 ms, sys: 56.5 ms, total: 523 ms
Wall time: 7.12 s

	profile_id	PLATFORM_NUMBER	CYCLE_NUMBER	TIME	LATITUDE	LONGITUDE	pace_Kd_file	pace_Kd_t_start	pace_Kd_t_end	pace_Kd_lat	pace_Kd_lon	pace_Kd_490
0	4903485_0033	4903485	33	2024-03-05 01:16:05.000000000	29.082600	-17.213600	PACE_OCI.20240305.L3m.DAY.KD.V3_1.Kd.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	29.062498	-17.229162	0.071
1	2902882_0077	2902882	77	2024-03-05 02:08:10.000000000	25.111515	148.146488	PACE_OCI.20240305.L3m.DAY.KD.V3_1.Kd.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	25.104164	148.145844	NaN
2	5906304_0116	5906304	116	2024-03-05 06:58:45.000999936	-34.152200	-165.736500	PACE_OCI.20240305.L3m.DAY.KD.V3_1.Kd.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	-34.145836	-165.729172	NaN
3	2903856_0019	2903856	19	2024-03-05 08:16:05.000999936	0.673300	-165.453300	PACE_OCI.20240305.L3m.DAY.KD.V3_1.Kd.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	0.687497	-165.437500	NaN
4	7901028_0055	7901028	55	2024-03-05 11:32:39.019000064	69.673916	4.204859	PACE_OCI.20240305.L3m.DAY.KD.V3_1.Kd.4km.nc	2024-03-05 00:08:58.225000+00:00	2024-03-06 02:07:24.895000+00:00	69.687500	4.187506	NaN

from pathlib import Path
from datetime import datetime
import pandas as pd

results_dir = Path("_temp_data/matchups")
results_dir.mkdir(exist_ok=True)

all_batches = []
batch_size = 10
var = "CHLA"
results = results
df = argo_chl_df
ds_var = "Kd"

for batch_idx, i in enumerate(range(0, len(results), batch_size), start=1):
    batch = results[i:i+batch_size]
    print(f"Batch {batch_idx}: {len(batch)} files: {datetime.now():%H:%M:%S}")

    # If this batch was already done, skip it
    batch_path = results_dir / f"{var}_matchups_{ds_var}_batch_{batch_idx:03d}.parquet"
    if batch_path.exists():
        print(f"  -> Skipping batch {batch_idx}, found {batch_path}")
        continue

    df_batch = run_batch(batch, argo_chl_df, ds_var_name="Kd", ds_vec_sel=490.0)

    # Save this batch immediately
    df_batch.to_parquet(batch_path, index=False)
    print(f"  -> Saved {len(df_batch)} rows to {batch_path}")

Batch 1: 10 files: 16:28:02
  -> Saved 164 rows to data/matchups/CHLA_matchups_Kd_batch_001.parquet
Batch 2: 10 files: 16:28:12
  -> Saved 175 rows to data/matchups/CHLA_matchups_Kd_batch_002.parquet
Batch 3: 10 files: 16:28:21
  -> Saved 190 rows to data/matchups/CHLA_matchups_Kd_batch_003.parquet
Batch 4: 10 files: 16:28:31
  -> Saved 187 rows to data/matchups/CHLA_matchups_Kd_batch_004.parquet
Batch 5: 10 files: 16:28:42
  -> Saved 187 rows to data/matchups/CHLA_matchups_Kd_batch_005.parquet
Batch 6: 10 files: 16:28:53
  -> Saved 176 rows to data/matchups/CHLA_matchups_Kd_batch_006.parquet
Batch 7: 10 files: 16:29:05
  -> Saved 183 rows to data/matchups/CHLA_matchups_Kd_batch_007.parquet
Batch 8: 10 files: 16:29:16
  -> Saved 206 rows to data/matchups/CHLA_matchups_Kd_batch_008.parquet
Batch 9: 10 files: 16:29:27
  -> Saved 206 rows to data/matchups/CHLA_matchups_Kd_batch_009.parquet
Batch 10: 10 files: 16:29:36
  -> Saved 196 rows to data/matchups/CHLA_matchups_Kd_batch_010.parquet
Batch 11: 10 files: 16:29:48
  -> Saved 204 rows to data/matchups/CHLA_matchups_Kd_batch_011.parquet
Batch 12: 10 files: 16:29:58
  -> Saved 224 rows to data/matchups/CHLA_matchups_Kd_batch_012.parquet
Batch 13: 10 files: 16:30:09
  -> Saved 218 rows to data/matchups/CHLA_matchups_Kd_batch_013.parquet
Batch 14: 10 files: 16:30:21
  -> Saved 206 rows to data/matchups/CHLA_matchups_Kd_batch_014.parquet
Batch 15: 10 files: 16:30:33
  -> Saved 233 rows to data/matchups/CHLA_matchups_Kd_batch_015.parquet
Batch 16: 10 files: 16:30:46
  -> Saved 224 rows to data/matchups/CHLA_matchups_Kd_batch_016.parquet
Batch 17: 10 files: 16:30:58
  -> Saved 216 rows to data/matchups/CHLA_matchups_Kd_batch_017.parquet
Batch 18: 10 files: 16:31:09
  -> Saved 244 rows to data/matchups/CHLA_matchups_Kd_batch_018.parquet
Batch 19: 10 files: 16:31:21
  -> Saved 231 rows to data/matchups/CHLA_matchups_Kd_batch_019.parquet
Batch 20: 10 files: 16:31:33
  -> Saved 204 rows to data/matchups/CHLA_matchups_Kd_batch_020.parquet
Batch 21: 10 files: 16:31:46
  -> Saved 227 rows to data/matchups/CHLA_matchups_Kd_batch_021.parquet
Batch 22: 10 files: 16:31:59
  -> Saved 231 rows to data/matchups/CHLA_matchups_Kd_batch_022.parquet
Batch 23: 10 files: 16:32:08
  -> Saved 226 rows to data/matchups/CHLA_matchups_Kd_batch_023.parquet
Batch 24: 10 files: 16:32:20
  -> Saved 217 rows to data/matchups/CHLA_matchups_Kd_batch_024.parquet
Batch 25: 10 files: 16:32:32
  -> Saved 214 rows to data/matchups/CHLA_matchups_Kd_batch_025.parquet
Batch 26: 10 files: 16:32:43
  -> Saved 232 rows to data/matchups/CHLA_matchups_Kd_batch_026.parquet
Batch 27: 10 files: 16:32:55
  -> Saved 218 rows to data/matchups/CHLA_matchups_Kd_batch_027.parquet
Batch 28: 10 files: 16:33:05
  -> Saved 254 rows to data/matchups/CHLA_matchups_Kd_batch_028.parquet
Batch 29: 10 files: 16:33:17
  -> Saved 259 rows to data/matchups/CHLA_matchups_Kd_batch_029.parquet
Batch 30: 10 files: 16:33:30
  -> Saved 240 rows to data/matchups/CHLA_matchups_Kd_batch_030.parquet
Batch 31: 10 files: 16:33:41
  -> Saved 249 rows to data/matchups/CHLA_matchups_Kd_batch_031.parquet
Batch 32: 10 files: 16:33:54
  -> Saved 255 rows to data/matchups/CHLA_matchups_Kd_batch_032.parquet
Batch 33: 10 files: 16:34:08
  -> Saved 265 rows to data/matchups/CHLA_matchups_Kd_batch_033.parquet
Batch 34: 10 files: 16:34:22
  -> Saved 273 rows to data/matchups/CHLA_matchups_Kd_batch_034.parquet
Batch 35: 10 files: 16:34:36
  -> Saved 281 rows to data/matchups/CHLA_matchups_Kd_batch_035.parquet
Batch 36: 10 files: 16:34:50
  -> Saved 277 rows to data/matchups/CHLA_matchups_Kd_batch_036.parquet
Batch 37: 10 files: 16:35:04
  -> Saved 265 rows to data/matchups/CHLA_matchups_Kd_batch_037.parquet
Batch 38: 10 files: 16:35:18
  -> Saved 262 rows to data/matchups/CHLA_matchups_Kd_batch_038.parquet
Batch 39: 10 files: 16:35:30
  -> Saved 247 rows to data/matchups/CHLA_matchups_Kd_batch_039.parquet
Batch 40: 10 files: 16:35:43
  -> Saved 294 rows to data/matchups/CHLA_matchups_Kd_batch_040.parquet
Batch 41: 10 files: 16:35:57
  -> Saved 296 rows to data/matchups/CHLA_matchups_Kd_batch_041.parquet
Batch 42: 10 files: 16:36:10
  -> Saved 290 rows to data/matchups/CHLA_matchups_Kd_batch_042.parquet
Batch 43: 10 files: 16:36:23
  -> Saved 295 rows to data/matchups/CHLA_matchups_Kd_batch_043.parquet
Batch 44: 10 files: 16:36:37
  -> Saved 267 rows to data/matchups/CHLA_matchups_Kd_batch_044.parquet
Batch 45: 10 files: 16:36:49
  -> Saved 274 rows to data/matchups/CHLA_matchups_Kd_batch_045.parquet
Batch 46: 10 files: 16:37:01
  -> Saved 281 rows to data/matchups/CHLA_matchups_Kd_batch_046.parquet
Batch 47: 10 files: 16:37:13
  -> Saved 279 rows to data/matchups/CHLA_matchups_Kd_batch_047.parquet
Batch 48: 10 files: 16:37:26
  -> Saved 249 rows to data/matchups/CHLA_matchups_Kd_batch_048.parquet
Batch 49: 10 files: 16:37:39
  -> Saved 281 rows to data/matchups/CHLA_matchups_Kd_batch_049.parquet
Batch 50: 10 files: 16:37:53
  -> Saved 296 rows to data/matchups/CHLA_matchups_Kd_batch_050.parquet
Batch 51: 10 files: 16:38:06
  -> Saved 293 rows to data/matchups/CHLA_matchups_Kd_batch_051.parquet
Batch 52: 10 files: 16:38:21
  -> Saved 319 rows to data/matchups/CHLA_matchups_Kd_batch_052.parquet
Batch 53: 10 files: 16:38:36
  -> Saved 303 rows to data/matchups/CHLA_matchups_Kd_batch_053.parquet
Batch 54: 10 files: 16:38:50
  -> Saved 309 rows to data/matchups/CHLA_matchups_Kd_batch_054.parquet
Batch 55: 10 files: 16:39:05
  -> Saved 313 rows to data/matchups/CHLA_matchups_Kd_batch_055.parquet
Batch 56: 10 files: 16:39:20
  -> Saved 294 rows to data/matchups/CHLA_matchups_Kd_batch_056.parquet
Batch 57: 10 files: 16:39:34
  -> Saved 247 rows to data/matchups/CHLA_matchups_Kd_batch_057.parquet
Batch 58: 10 files: 16:39:45
  -> Saved 282 rows to data/matchups/CHLA_matchups_Kd_batch_058.parquet
Batch 59: 10 files: 16:39:59
  -> Saved 290 rows to data/matchups/CHLA_matchups_Kd_batch_059.parquet
Batch 60: 10 files: 16:40:12
  -> Saved 298 rows to data/matchups/CHLA_matchups_Kd_batch_060.parquet
Batch 61: 10 files: 16:40:24
  -> Saved 318 rows to data/matchups/CHLA_matchups_Kd_batch_061.parquet
Batch 62: 10 files: 16:40:38
  -> Saved 300 rows to data/matchups/CHLA_matchups_Kd_batch_062.parquet
Batch 63: 10 files: 16:40:50
  -> Saved 306 rows to data/matchups/CHLA_matchups_Kd_batch_063.parquet
Batch 64: 10 files: 16:41:03
  -> Saved 312 rows to data/matchups/CHLA_matchups_Kd_batch_064.parquet
Batch 65: 10 files: 16:41:17
  -> Saved 299 rows to data/matchups/CHLA_matchups_Kd_batch_065.parquet
Batch 66: 10 files: 16:41:30
  -> Saved 294 rows to data/matchups/CHLA_matchups_Kd_batch_066.parquet
Batch 67: 10 files: 16:41:44
  -> Saved 329 rows to data/matchups/CHLA_matchups_Kd_batch_067.parquet
Batch 68: 10 files: 16:41:57
  -> Saved 294 rows to data/matchups/CHLA_matchups_Kd_batch_068.parquet
Batch 69: 10 files: 16:42:11
  -> Saved 275 rows to data/matchups/CHLA_matchups_Kd_batch_069.parquet
Batch 70: 10 files: 16:42:23
  -> Saved 277 rows to data/matchups/CHLA_matchups_Kd_batch_070.parquet
Batch 71: 10 files: 16:42:35
  -> Saved 264 rows to data/matchups/CHLA_matchups_Kd_batch_071.parquet
Batch 72: 2 files: 16:42:47
  -> Saved 35 rows to data/matchups/CHLA_matchups_Kd_batch_072.parquet

# When everything is done, you can merge all batches:
from pathlib import Path
import pandas as pd

results_dir = Path("_temp_data/matchups")
var = "CHLA"
ds_var = "Kd"

batch_files = sorted(results_dir.glob(f"{var}_matchups_{ds_var}_batch_*.parquet"))
dfs = [pd.read_parquet(f) for f in batch_files]
df_all = pd.concat(dfs, ignore_index=True)
df_all.to_parquet(f"{results_dir}/{var}_argo_{ds_var}_all.parquet", index=False)

Merge all the PACE data into one parquet

This has PACE data only for profiles. clean has duplicates removed and rows with no Rrs removed. Saved to CHLA_argo_Rrs_chlor_a_Kd.parquet.

# When everything is done, you can merge all batches:
from pathlib import Path
import pandas as pd
import numpy as np

results_dir = Path("_temp_data/matchups")
var = "CHLA"

df_all_kd = pd.read_parquet(f"{results_dir}/{var}_argo_Kd_all.parquet")
df_all_chl = pd.read_parquet(f"{results_dir}/{var}_argo_chlor_a_all.parquet")
df_all_rrs = pd.read_parquet(f"{results_dir}/{var}_argo_Rrs_all.parquet")

# check
n = 6
assert np.array_equal(
    df_all_chl.iloc[:, :n].values,
    df_all_rrs.iloc[:, :n].values
), "First 6 column values differ"

assert np.array_equal(
    df_all_kd.iloc[:, :n].values,
    df_all_rrs.iloc[:, :n].values
), "First 6 column values differ"
#n = 7:11
assert np.array_equal(
    df_all_chl.iloc[:, 7:11].values,
    df_all_rrs.iloc[:, 7:11].values
), "t/lat/lon values differ"
assert np.array_equal(
    df_all_kd.iloc[:, 7:11].values,
    df_all_rrs.iloc[:, 7:11].values
), "t/lat/lon values differ"

# columns to add
df_chl_extra = df_all_chl["pace_chlor_a"]
df_kd_extra = df_all_kd["pace_Kd_490"]
# Horizontal concat: rrs on the left, extras on the right
df_merged = pd.concat([df_all_rrs, df_chl_extra, df_kd_extra], axis=1)
df_merged.to_parquet(f"{resuls_dir}/{var}_argo_Rrs_chlor_a_Kd_all.parquet", index=False)

# Cleaned; no missing Rrs
# Duplicates replaced with the PACE data that is closest to TIME

from pathlib import Path
import pandas as pd
results_dir = Path("_temp_data/matchups")
var = "CHLA"

df_merged = pd.read_parquet(f"{results_dir}/{var}_argo_Rrs_chlor_a_Kd_all.parquet")
rrs_cols = [c for c in df_merged.columns if c.startswith("pace_Rrs_") and c[-1].isdigit()]
df_merged_clean = df_merged.dropna(subset=rrs_cols, how="all").reset_index(drop=True)

df = df_merged_clean

# Parse all times as UTC-aware datetimes
for col in ["TIME", "pace_Rrs_t_start", "pace_Rrs_t_end"]:
    df[col] = pd.to_datetime(df[col], utc=True)

# is file NRT
df["nrt"] = [("NRT" in f) for f in df["pace_Rrs_file"]]
idx = df.groupby("profile_id")["nrt"].idxmin()
df = df.loc[idx].drop(columns=["nrt"]).reset_index(drop=True)

# center of the PACE time window
df["pace_center"] = df["pace_Rrs_t_start"] + (
    df["pace_Rrs_t_end"] - df["pace_Rrs_t_start"]
) / 2

# 2. absolute time difference between profile TIME and window center
df["time_diff"] = (df["TIME"] - df["pace_center"]).abs()

# 3. for each profile_id, keep the row with smallest time_diff
idx = df.groupby("profile_id")["time_diff"].idxmin()

df_dedup = df.loc[idx].drop(columns=["pace_center", "time_diff"]).reset_index(drop=True)
df_dedup = df_dedup.sort_values(by="TIME").reset_index(drop=True)
df_dedup.to_parquet(f"{results_dir}/{var}_argo_Rss_chlor_a_Kd.parquet", index=False)

Create the final parquet by merging the Argo and PACE data

All Bio-Argo profiles where there is Rrs data. If there are 2 PACE files that cover the time of an Argo profiles, which can happen if time is near midnight or there is delayed and NRT data, then choose the delayed data (higher QC) first. If duplicates still exist, chose the PACE data that is closest in time to the Argo data.

# merge the Argo and PACE data. Only profiles with Rrs data
from pathlib import Path
results_dir = Path("_temp_data/matchups")
var = "CHLA"

import pandas as pd
out_path = f"data/{var}_argo_profiles.parquet"
profiles = pd.read_parquet(out_path)
profiles["TIME"] = pd.to_datetime(profiles["TIME"], utc=True)
# cleaned version; no dups; must have Rrs
out_path = f"{results_dir}/{var}_argo_Rrs_chlor_a_Kd_all.parquet"
pace = pd.read_parquet(out_path)
print(len(profiles))
print(len(pace))

15833
18119

# Cleaned; no missing Rrs
# Duplicates replaced with the PACE data that is closest to TIME

import pandas as pd
from pathlib import Path
results_dir = Path("_temp_data/matchups")
var = "CHLA"

df_merged = pd.read_parquet(f"{results_dir}/{var}_argo_Rrs_chlor_a_Kd_all.parquet")

df = df_merged

# Parse all times as UTC-aware datetimes
for col in ["TIME", "pace_Rrs_t_start", "pace_Rrs_t_end"]:
    df[col] = pd.to_datetime(df[col], utc=True)

# is file NRT
df["nrt"] = [("NRT" in f) for f in df["pace_Rrs_file"]]
idx = df.groupby("profile_id")["nrt"].idxmin()
df = df.loc[idx].drop(columns=["nrt"]).reset_index(drop=True)

# Just in case there are 2 files due to slightly overlapping time windows
# though turns out there were not any
# center of the PACE time window
df["pace_center"] = df["pace_Rrs_t_start"] + (
    df["pace_Rrs_t_end"] - df["pace_Rrs_t_start"]
) / 2

# 2. absolute time difference between profile TIME and window center
df["time_diff"] = (df["TIME"] - df["pace_center"]).abs()

# 3. for each profile_id, keep the row with smallest time_diff
idx = df.groupby("profile_id")["time_diff"].idxmin()

df_dedup = df.loc[idx].drop(columns=["pace_center", "time_diff"]).reset_index(drop=True)
df_dedup = df_dedup.sort_values(by="TIME").reset_index(drop=True)
print(df_dedup.shape)
# double-check
df_dedup['profile_id'].duplicated().any()

(14916, 185)

np.False_

# Merge
keys = ["profile_id", "PLATFORM_NUMBER", "CYCLE_NUMBER",
        "TIME", "LATITUDE", "LONGITUDE"]
df_merged = profiles.merge(df_dedup, on=keys, how="inner")
# fix col order
cols = df_merged.columns.tolist()
cols = ["profile_id"] + [c for c in cols if c != "profile_id"]
df_merged = df_merged[cols].sort_values(by="TIME").reset_index(drop=True)
df_merged.shape

(14916, 225)

out_path = "data/CHLA_argo_profiles_plus_PACE.parquet"
df_merged.to_parquet(out_path)

Save final version with metadata

This has BGC-Argo and PACE matchups.

import pyarrow as pa
import pyarrow.parquet as pq
from datetime import datetime
import pandas as pd

out_path = "data/CHLA_argo_profiles_plus_PACE.parquet"
df = pd.read_parquet(out_path)

table = pa.Table.from_pandas(df)

file_meta = {
    "title": "Global Bio-Argo CHLA profile metrics (0 to 200 m, 10 m bins) with PACE Rrs, chlor_a and Kd_490 matchups",
    "creator": "Eli Holmes / NOAA https://orcid.org/0000-0001-9128-8393",
    "created": datetime.utcnow().isoformat() + "Z",
    "source": (
        "BGC-Argo (via argopy) and Daily 4km PACE data v 3.1 collections "
        "PACE_OCI_L3M_RRS, PACE_OCI_L3M_CHL and PACE_OCI_L3M_KD via NASA Earthdata. "
        "Argo (2000). Argo float data and metadata from Global Data Assembly Centre "
        "(Argo GDAC). SEANOE. https://doi.org/10.17882/42182"
    ),
    "description": (
        "All BGC-Argo data Mar 2024 to Nov 2025 with CHLA variable was downloaded. "
        "Per-profile depth-binned CHLA means (0–200 m by 10 m bins) were computed for each depth bin. "
        "No QC filtering on the values was done using the CHLA_QC variable. "
        "All profiles were kept even if some binned averages were missing. "
        "PACE Rrs for all wavelengths, chlor_a, and Kd_490 were extracted from Level 3 4km v 3.1 Daily files. "
        "Matching was done by first selecting all profiles with TIME within 24 hours of t_start in the "
        "PACE Level 3 file. Note: t_start in the netcdf attributes was used, not the day in the netcdf filename or "
        "in the NASA Earthdata CMS. Once all profiles within that timerange were found, the LATITUDE/LONGITUDE point "
        "for the Argo profile was matched to the PACE Level 3 4km grid via ds.sel(lon=LONGITUDE, lat=LATITUDE, method='nearest') "
        "where ds is an xarray Dataset formed by reading in the PACE file. "
        "The actual PACE files used are listed in the dataset under pace_var_file. "
        "Note: the PACE data is heavily cloud-affected and the majority (≈80%) of PACE pixels are NaN."
        "Data were accessed using earthaccess Python package, example "
        "results = earthaccess.search_data(short_name = 'PACE_OCI_L3M_KD', temporal = ('2024-03-01', '2025-11-30'), granule_name='*.DAY.*.4km.*')"
    ),

    "profile_id_definition": "profile_id = PLATFORM_NUMBER (7 digits) + '_' + CYCLE_NUMBER (4 digits)",
    "PLATFORM_NUMBER_definition": "PLATFORM_NUMBER from BGC-Argo identifying the buoy.",
    "CYCLE_NUMBER_definition": "CYCLE_NUMBER from BGC-Argo identifying the ascent/descent cycle.",
    "TIME_definition": "TIME in UTC from BGC-Argo. One time is assigned to each ascent/descent cycle.",
    "LATITUDE_definition": "LATITUDE from BGC-Argo. One is assigned to each ascent/descent cycle.",
    "LONGITUDE_definition": "LONGITUDE from BGC-Argo. One is assigned to each ascent/descent cycle.",

    "CHLA_A_B_definition": (
        "Depth-binned averages of CHLA. Computed as the average of all individual CHLA measurements within the pressure interval "
        "(PRES>=A and PRES<B), where PRES is dbar and signifies depth. "
        "No QC was done on the CHLA data before averaging."
    ),
    "CHLA_A_B_N_definition": (
        "Number of individual CHLA measurements within the pressure interval "
        "(PRES>=A and PRES<B) used to compute the depth-binned mean."
    ),

    "pace_Rrs_lat_definition": "The matched latitude from the PACE Level 3 grid.",
    "pace_Rrs_lon_definition": "The matched longitude from the PACE Level 3 grid.",
    "pace_Rrs_t_start_definition": "Start time of the swath data used to create the Level 3 4km file. In UTC, from netcdf attributes.",
    "pace_Rrs_t_end_definition": "End time of the swath data used to create the Level 3 4km file. In UTC, from netcdf attributes.",
    "pace_Rrs_file_definition": "Filename for the Level 3 4km file. Only Rrs is shown but chlor_a and Kd_490 are analogous.",
    "pace_Rrs_A_definition": (
        "PACE_OCI_L3M_RRS Level 3 4km remote-sensing reflectance for wavelength A, "
        "where A is the center wavelength in nanometers (e.g., pace_Rrs_443 for 443 nm), "
        "extracted from PACE v 3.1 Daily files."
    ),

    "pace_chlor_a_definition": "PACE_OCI_L3M_CHL Level 3 4km chlor_a extracted from PACE v 3.1 Daily files.",
    "pace_Kd_490_definition": "PACE_OCI_L3M_KD Level 3 4km Kd_490 extracted from PACE v 3.1 Daily files.",

    "variable_LATITUDE_standard_name": "latitude",
    "variable_LATITUDE_units": "degrees_north",
    "variable_LONGITUDE_standard_name": "longitude",
    "variable_LONGITUDE_units": "degrees_east",

    "variable_pace_Rrs_lat_standard_name": "latitude",
    "variable_pace_Rrs_lat_units": "degrees_north",
    "variable_pace_Rrs_lon_standard_name": "longitude",
    "variable_pace_Rrs_lon_units": "degrees_east",
    "variable_pace_Rrs_t_start_standard_name": "time",
    "variable_pace_Rrs_t_start_units": "UTC",
    "variable_pace_Rrs_t_end_standard_name": "time",
    "variable_pace_Rrs_t_end_units": "UTC",

    "variable_pace_CHLA_prefix_definition": (
        "All columns whose names start with 'CHLA_' followed by two numbers "
        "are the averaged CHLA within a depth bin defined by the numbers. "
        "For example, 'CHLA_10_20' is the average CHLA between PRES>=10 and PRES<20 dbar."
    ),

    "CHLA_processing_description": (
        "CHLA values were taken directly from the BGC-Argo variable 'CHLA' "
        "(mg m-3). No additional sensor corrections or non-photochemical "
        "quenching adjustments were applied. CHLA_QC values were not used to "
        "filter measurements. CHLA measurements were aggregated into 10 m "
        "pressure bins between 0 and 200 dbar using arithmetic means."
    ),

    "CHLA_measurement_description": (
        "BGC-Argo chlorophyll-a (CHLA) is measured using a submersible "
        "chlorophyll fluorometer mounted on the float. The sensor emits blue light "
        "(~470 nm) and detects the resulting chlorophyll fluorescence near ~695 nm. "
        "Fluorescence intensity is converted onboard to chlorophyll-a concentration "
        "using factory calibration coefficients and reported in mg m-3 as the raw "
        "'CHLA' variable. Additional processing recommended by the BGC-Argo community "
        "(e.g., non-photochemical quenching correction, dark-count correction, and "
        "delayed-mode quality-control adjustments) was not applied; this dataset uses "
        "the unadjusted CHLA values provided in the core BGC-Argo data stream."
    ),

    "variable_CHLA_standard_name": "mass_concentration_of_chlorophyll_a_in_sea_water",
    "variable_CHLA_units": "mg m-3",
    "variable_CHLA_A_B_N_long_name": "count of raw CHLA measurements in each depth bin",
    "variable_CHLA_A_B_N_units": "1",

    "variable_pace_Rrs_prefix_definition": (
        "All columns whose names start with 'pace_Rrs_' contain PACE OCI "
        "remote-sensing reflectance (Rrs) at the wavelength given by the suffix "
        "in nanometers. For example, 'pace_Rrs_443' is Rrs at 443 nm. "
        "Rrs is the ratio of water-leaving radiance to downwelling irradiance "
        "just above the sea surface."
    ),
    "variable_pace_Rrs_long_name": "Remote sensing reflectance",
    "variable_pace_Rrs_standard_name": (
        "surface_ratio_of_upwelling_radiance_emerging_from_sea_water_to_"
        "downwelling_radiative_flux_in_air"
    ),
    "variable_pace_Rrs_units": "sr-1",

    "Rrs_measurement_definition": (
        "Remote-sensing reflectance (Rrs) is the ratio of water-leaving radiance "
        "to downwelling irradiance just above the sea surface (sr-1). "
        "Rrs(λ) from PACE OCI is derived from top-of-atmosphere radiances "
        "after atmospheric correction that removes molecular scattering, "
        "aerosol scattering, and surface glint contributions. "
        "Rrs represents the spectral signature of the ocean water column "
        "and is the primary input for bio-optical algorithms. "
        "PACE OCI provides hyperspectral Rrs from 350–890 nm at 5 nm resolution. "
        "pace_Rrs_λ variables in this dataset correspond to center wavelengths "
        "equal to the value in the variable name (e.g., pace_Rrs_443 for 443 nm)."
    ),

    "pace_chlor_a_long_name": "Chlorophyll Concentration, OCI Algorithm",
    "pace_chlor_a_standard_name": "mass_concentration_of_chlorophyll_a_in_sea_water",
    "pace_chlor_a_units": "mg m-3",
    "pace_chlor_a_valid_min": "0.001",
    "pace_chlor_a_valid_max": "100.0",

    "pace_chlor_a_measurement_definition": (
        "From PACE v 3.1 Level 3 files: PACE OCI chlorophyll-a concentration (chlor_a) "
        "is computed using the OCI Chlorophyll Algorithm (CI algorithm) described by "
        "Hu, Lee, and Franz (2012). The CI algorithm estimates chlorophyll-a "
        "concentration from hyperspectral remote-sensing reflectance (Rrs) using a "
        "three-band baseline difference approach optimized for clear to moderately "
        "productive waters. Values represent near-surface chlorophyll-a concentration "
        "in mg m-3. See: Hu, C., Lee Z., and Franz, B.A. (2012). "
        "'Chlorophyll-a algorithms for oligotrophic oceans: A novel approach based on "
        "three-band reflectance difference,' J. Geophys. Res., 117, C01011."
    ),

    "pace_Kd_490_standard_name": "attenuation_of_downwelling_radiative_flux_in_sea_water",
    "pace_Kd_490_units": "m-1",

    "pace_Kd_490_measurement_definition": (
        "Diffuse attenuation coefficient for downwelling irradiance at 490 nm (Kd_490), "
        "retrieved from PACE OCI Rrs. "
        "Kd_490 describes the rate at which light at 490 nm decays with depth due to "
        "absorption and scattering in the water column. Higher Kd_490 values indicate "
        "optically darker, more turbid, or more absorbing waters. "
        "From PACE v 3.1 Level 3 files; key references include: "
        "Lee, Z.P., M. Darecki, K.L. Carder, C.O. Davis, D. Stramski, W.J. Rhea, "
        "'Diffuse Attenuation coefficient of downwelling irradiance: An evaluation of remote sensing methods' (2005), "
        "doi:10.1029/2004JC002573; and Zhongping Lee, Chuanmin Hu, Shaoling Shang, "
        "Keping Du, Marlon Lewis, Robert Arnone, and Robert Brewin, "
        "'Penetration of UV-visible solar radiation in the global oceans: Insights from ocean color remote sensing' (2013), "
        "doi:10.1002/jgrc.20308."
    ),

    "spatiotemporal_coverage_time_start": "2024-03-01T00:00:00Z",
    "spatiotemporal_coverage_time_end": "2025-11-30T23:59:59Z",
    "spatiotemporal_coverage_lat_min": "-90.0",
    "spatiotemporal_coverage_lat_max": "90.0",
    "spatiotemporal_coverage_lon_min": "-180.0",
    "spatiotemporal_coverage_lon_max": "180.0",

    "license": "Open access (Argo Data Policy); unrestricted use with attribution."
}

table = table.replace_schema_metadata(file_meta)

out_path = "data/CHLA_argo_profiles_plus_PACE.parquet"
pq.write_table(table, out_path)

# Check metadata

import pyarrow.parquet as pq
out_path = "data/CHLA_argo_profiles_plus_PACE.parquet"
t = pq.read_table(out_path)
t.schema.metadata

{b'title': b'Global Bio-Argo CHLA profile metrics (0 to 200 m, 10 m bins) with PACE Rrs, chlor_a and Kd_490 matchups',
 b'creator': b'Eli Holmes / NOAA https://orcid.org/0000-0001-9128-8393',
 b'created': b'2025-12-03T23:29:50.743998Z',
 b'source': b'BGC-Argo (via argopy) and Daily 4km PACE data v 3.1 collections PACE_OCI_L3M_RRS, PACE_OCI_L3M_CHL and PACE_OCI_L3M_KD via NASA Earthdata. Argo (2000). Argo float data and metadata from Global Data Assembly Centre (Argo GDAC). SEANOE. https://doi.org/10.17882/42182',
 b'description': b"All BGC-Argo data Mar 2024 to Nov 2025 with CHLA variable was downloaded. Per-profile depth-binned CHLA means (0\xe2\x80\x93200 m by 10 m bins) were computed for each depth bin. No QC filtering on the values was done using the CHLA_QC variable. All profiles were kept even if some binned averages were missing. PACE Rrs for all wavelengths, chlor_a, and Kd_490 were extracted from Level 3 4km v 3.1 Daily files. Matching was done by first selecting all profiles with TIME within 24 hours of t_start in the PACE Level 3 file. Note: t_start in the netcdf attributes was used, not the day in the netcdf filename or in the NASA Earthdata CMS. Once all profiles within that timerange were found, the LATITUDE/LONGITUDE point for the Argo profile was matched to the PACE Level 3 4km grid via ds.sel(lon=LONGITUDE, lat=LATITUDE, method='nearest') where ds is an xarray Dataset formed by reading in the PACE file. The actual PACE files used are listed in the dataset under pace_var_file. Note: the PACE data is heavily cloud-affected and the majority (\xe2\x89\x8880%) of PACE pixels are NaN.Data were accessed using earthaccess Python package, example results = earthaccess.search_data(short_name = 'PACE_OCI_L3M_KD', temporal = ('2024-03-01', '2025-11-30'), granule_name='*.DAY.*.4km.*')",
 b'profile_id_definition': b"profile_id = PLATFORM_NUMBER (7 digits) + '_' + CYCLE_NUMBER (4 digits)",
 b'PLATFORM_NUMBER_definition': b'PLATFORM_NUMBER from BGC-Argo identifying the buoy.',
 b'CYCLE_NUMBER_definition': b'CYCLE_NUMBER from BGC-Argo identifying the ascent/descent cycle.',
 b'TIME_definition': b'TIME in UTC from BGC-Argo. One time is assigned to each ascent/descent cycle.',
 b'LATITUDE_definition': b'LATITUDE from BGC-Argo. One is assigned to each ascent/descent cycle.',
 b'LONGITUDE_definition': b'LONGITUDE from BGC-Argo. One is assigned to each ascent/descent cycle.',
 b'CHLA_A_B_definition': b'Depth-binned averages of CHLA. Computed as the average of all individual CHLA measurements within the pressure interval (PRES>=A and PRES<B), where PRES is dbar and signifies depth. No QC was done on the CHLA data before averaging.',
 b'CHLA_A_B_N_definition': b'Number of individual CHLA measurements within the pressure interval (PRES>=A and PRES<B) used to compute the depth-binned mean.',
 b'pace_Rrs_lat_definition': b'The matched latitude from the PACE Level 3 grid.',
 b'pace_Rrs_lon_definition': b'The matched longitude from the PACE Level 3 grid.',
 b'pace_Rrs_t_start_definition': b'Start time of the swath data used to create the Level 3 4km file. In UTC, from netcdf attributes.',
 b'pace_Rrs_t_end_definition': b'End time of the swath data used to create the Level 3 4km file. In UTC, from netcdf attributes.',
 b'pace_Rrs_file_definition': b'Filename for the Level 3 4km file. Only Rrs is shown but chlor_a and Kd_490 are analogous.',
 b'pace_Rrs_A_definition': b'PACE_OCI_L3M_RRS Level 3 4km remote-sensing reflectance for wavelength A, where A is the center wavelength in nanometers (e.g., pace_Rrs_443 for 443 nm), extracted from PACE v 3.1 Daily files.',
 b'pace_chlor_a_definition': b'PACE_OCI_L3M_CHL Level 3 4km chlor_a extracted from PACE v 3.1 Daily files.',
 b'pace_Kd_490_definition': b'PACE_OCI_L3M_KD Level 3 4km Kd_490 extracted from PACE v 3.1 Daily files.',
 b'variable_LATITUDE_standard_name': b'latitude',
 b'variable_LATITUDE_units': b'degrees_north',
 b'variable_LONGITUDE_standard_name': b'longitude',
 b'variable_LONGITUDE_units': b'degrees_east',
 b'variable_pace_Rrs_lat_standard_name': b'latitude',
 b'variable_pace_Rrs_lat_units': b'degrees_north',
 b'variable_pace_Rrs_lon_standard_name': b'longitude',
 b'variable_pace_Rrs_lon_units': b'degrees_east',
 b'variable_pace_Rrs_t_start_standard_name': b'time',
 b'variable_pace_Rrs_t_start_units': b'UTC',
 b'variable_pace_Rrs_t_end_standard_name': b'time',
 b'variable_pace_Rrs_t_end_units': b'UTC',
 b'variable_pace_CHLA_prefix_definition': b"All columns whose names start with 'CHLA_' followed by two numbers are the averaged CHLA within a depth bin defined by the numbers. For example, 'CHLA_10_20' is the average CHLA between PRES>=10 and PRES<20 dbar.",
 b'CHLA_processing_description': b"CHLA values were taken directly from the BGC-Argo variable 'CHLA' (mg m-3). No additional sensor corrections or non-photochemical quenching adjustments were applied. CHLA_QC values were not used to filter measurements. CHLA measurements were aggregated into 10 m pressure bins between 0 and 200 dbar using arithmetic means.",
 b'CHLA_measurement_description': b"BGC-Argo chlorophyll-a (CHLA) is measured using a submersible chlorophyll fluorometer mounted on the float. The sensor emits blue light (~470 nm) and detects the resulting chlorophyll fluorescence near ~695 nm. Fluorescence intensity is converted onboard to chlorophyll-a concentration using factory calibration coefficients and reported in mg m-3 as the raw 'CHLA' variable. Additional processing recommended by the BGC-Argo community (e.g., non-photochemical quenching correction, dark-count correction, and delayed-mode quality-control adjustments) was not applied; this dataset uses the unadjusted CHLA values provided in the core BGC-Argo data stream.",
 b'variable_CHLA_standard_name': b'mass_concentration_of_chlorophyll_a_in_sea_water',
 b'variable_CHLA_units': b'mg m-3',
 b'variable_CHLA_A_B_N_long_name': b'count of raw CHLA measurements in each depth bin',
 b'variable_CHLA_A_B_N_units': b'1',
 b'variable_pace_Rrs_prefix_definition': b"All columns whose names start with 'pace_Rrs_' contain PACE OCI remote-sensing reflectance (Rrs) at the wavelength given by the suffix in nanometers. For example, 'pace_Rrs_443' is Rrs at 443 nm. Rrs is the ratio of water-leaving radiance to downwelling irradiance just above the sea surface.",
 b'variable_pace_Rrs_long_name': b'Remote sensing reflectance',
 b'variable_pace_Rrs_standard_name': b'surface_ratio_of_upwelling_radiance_emerging_from_sea_water_to_downwelling_radiative_flux_in_air',
 b'variable_pace_Rrs_units': b'sr-1',
 b'Rrs_measurement_definition': b'Remote-sensing reflectance (Rrs) is the ratio of water-leaving radiance to downwelling irradiance just above the sea surface (sr-1). Rrs(\xce\xbb) from PACE OCI is derived from top-of-atmosphere radiances after atmospheric correction that removes molecular scattering, aerosol scattering, and surface glint contributions. Rrs represents the spectral signature of the ocean water column and is the primary input for bio-optical algorithms. PACE OCI provides hyperspectral Rrs from 350\xe2\x80\x93890 nm at 5 nm resolution. pace_Rrs_\xce\xbb variables in this dataset correspond to center wavelengths equal to the value in the variable name (e.g., pace_Rrs_443 for 443 nm).',
 b'pace_chlor_a_long_name': b'Chlorophyll Concentration, OCI Algorithm',
 b'pace_chlor_a_standard_name': b'mass_concentration_of_chlorophyll_a_in_sea_water',
 b'pace_chlor_a_units': b'mg m-3',
 b'pace_chlor_a_valid_min': b'0.001',
 b'pace_chlor_a_valid_max': b'100.0',
 b'pace_chlor_a_measurement_definition': b"From PACE v 3.1 Level 3 files: PACE OCI chlorophyll-a concentration (chlor_a) is computed using the OCI Chlorophyll Algorithm (CI algorithm) described by Hu, Lee, and Franz (2012). The CI algorithm estimates chlorophyll-a concentration from hyperspectral remote-sensing reflectance (Rrs) using a three-band baseline difference approach optimized for clear to moderately productive waters. Values represent near-surface chlorophyll-a concentration in mg m-3. See: Hu, C., Lee Z., and Franz, B.A. (2012). 'Chlorophyll-a algorithms for oligotrophic oceans: A novel approach based on three-band reflectance difference,' J. Geophys. Res., 117, C01011.",
 b'pace_Kd_490_standard_name': b'attenuation_of_downwelling_radiative_flux_in_sea_water',
 b'pace_Kd_490_units': b'm-1',
 b'pace_Kd_490_measurement_definition': b"Diffuse attenuation coefficient for downwelling irradiance at 490 nm (Kd_490), retrieved from PACE OCI Rrs. Kd_490 describes the rate at which light at 490 nm decays with depth due to absorption and scattering in the water column. Higher Kd_490 values indicate optically darker, more turbid, or more absorbing waters. From PACE v 3.1 Level 3 files; key references include: Lee, Z.P., M. Darecki, K.L. Carder, C.O. Davis, D. Stramski, W.J. Rhea, 'Diffuse Attenuation coefficient of downwelling irradiance: An evaluation of remote sensing methods' (2005), doi:10.1029/2004JC002573; and Zhongping Lee, Chuanmin Hu, Shaoling Shang, Keping Du, Marlon Lewis, Robert Arnone, and Robert Brewin, 'Penetration of UV-visible solar radiation in the global oceans: Insights from ocean color remote sensing' (2013), doi:10.1002/jgrc.20308.",
 b'spatiotemporal_coverage_time_start': b'2024-03-01T00:00:00Z',
 b'spatiotemporal_coverage_time_end': b'2025-11-30T23:59:59Z',
 b'spatiotemporal_coverage_lat_min': b'-90.0',
 b'spatiotemporal_coverage_lat_max': b'90.0',
 b'spatiotemporal_coverage_lon_min': b'-180.0',
 b'spatiotemporal_coverage_lon_max': b'180.0',
 b'license': b'Open access (Argo Data Policy); unrestricted use with attribution.'}

Update our STAC entry to include this new dataset

# --- Custom python functions ---
import os, importlib
# Looks to see if you have the file already and if not, downloads from GitHub
if not os.path.exists("ml_utils.py"):
    !wget -q https://raw.githubusercontent.com/fish-pace/2025-tutorials/main/ml_utils.py

import ml_utils as mu
importlib.reload(mu)

<module 'ml_utils' from '/home/jovyan/2025-tutorials/ml_utils.py'>

# Create or update the STAC entry for the PACE matchup file

collection_path = "data/tutorial_data_collection.json"

collection = mu.load_or_create_collection(collection_path)

pace_item_id = "global-bio-argo-chla-profile-metrics-0-200m-10m-bins-with-pace-oci-matchups"
pace_file_name = "CHLA_argo_profiles_plus_PACE.parquet"

# raw GitHub URL pattern
pace_href = f"https://raw.githubusercontent.com/fish-pace/2025-tutorials/main/data/{pace_file_name}"

# Notebook that creates / documents this dataset
pace_notebook_href = "https://github.com/fish-pace/2025-tutorials/blob/main/argo-matchups.ipynb"

collection = mu.add_or_update_item(
    collection,
    item_id=pace_item_id,
    asset_href=pace_href,
    title=(
        "Global Bio-Argo CHLA profile metrics (0–200 m, 10 m bins) "
        "with PACE Rrs, chlor_a, and Kd_490 matchups"
    ),
    description=(
        "Per-profile CHLA metrics from all global BGC-Argo floats from Mar 2024 to Nov 2025, "
        "depth-binned from 0–200 m in 10 m bins using unadjusted CHLA values, "
        "matched to PACE OCI Level-3 4 km v3.1 Daily Rrs, chlor_a, and Kd_490. "
        "Profiles are matched to PACE Level-3 pixels within 24 hours of the file t_start "
        "attribute and to the nearest 4 km grid cell in latitude/longitude."
    ),
    start_datetime="2024-03-01T00:00:00Z",
    end_datetime="2025-11-30T23:59:59Z",
    extra_properties={
        "license": "Open access (Argo Data Policy); unrestricted use with attribution.",
        "variables": ["CHLA", "Rrs", "chlor_a", "Kd_490"],
        "platform": "BGC-Argo + PACE OCI",
        "tutorial_notebook": pace_notebook_href,
        "file_name": pace_file_name
    }
)

mu.save_collection(collection, collection_path)

mu.stac_to_readme(
    "data/tutorial_data_collection.json",
    readme_path="data/README.md",
    repo_raw_base="https://raw.githubusercontent.com/fish-pace/2025-tutorials/main"
)

README.md written to data/README.md

Summary

This completes the preparation of our Bio-Argo + PACE matchups dataset. Now that we have the data we can use is to train a model to predict CHLA using Bio-Argo and compare to PACE chlor_a from Rrs ratios.

The Bio-Argo and PACE (satellite-derived) chlorophyll-a estimates will not match. One is based on reflectance from the water column while the other is in-situ reflectance. But that are correlated. This plot shows a oft observed pattern where the satellite derived estimate is higher when surface CHLA is lower. Conversely, the in-situ surface measurement is a bit higher when CHLA is higher. But note that we don’t have many in-situ measurements over 0 (on log10 scale) so about 1 on the non-log scale. A bloom would be like 1.4 (on the log10 scale) so we really don’t sample any bloom. That’s a big problem with our Bio-Argo dataset. Alas.

import numpy as np
import matplotlib.pyplot as plt
from sklearn.metrics import r2_score, mean_squared_error

df = pd.read_parquet("data/CHLA_argo_profiles_plus_PACE.parquet")
df_clean = df.dropna(subset=["CHLA_0_10"])

# Take logs (natural log; use np.log10 if you prefer log10)
y_argo = df_clean["CHLA_0_10"].values
y_pace = df_clean["pace_chlor_a"].values

# Mask: positive & finite in both
mask = (
    np.isfinite(y_argo) &
    np.isfinite(y_pace) &
    (y_argo > 0) &
    (y_pace > 0)
)

y_argo = y_argo[mask]
y_pace = y_pace[mask]

y_argo = np.log10(y_argo)
y_pace = np.log10(y_pace)

# Scatter plot
plt.figure(figsize=(5, 5))
plt.scatter(y_argo, y_pace, s=3, alpha=0.3)

# 1:1 line
lims = [
    min(y_argo.min(), y_pace.min()),
    max(y_argo.max(), y_pace.max())
]
plt.plot(lims, lims, "k--", linewidth=1)
plt.xlim(lims)
plt.ylim(lims)

plt.xlabel("log10 Chl-a (argo 0 to 10m)")
plt.ylabel("log10 Chl-a (pace chlor_a)")
plt.title("Argo surface compared to PACE CHLA")
plt.tight_layout()
plt.show()

Illustrate the effect of solar hour

We can look at the bias between our in-situ and satellite derived estimates to see the effect of solar hour. Solar hour is known to be a big issue for Bio-Argo CHLA sensor and we didn’t do anything to correct for that. We will correct for that indirectly by including solar hour in our Boosted Regression Tree model.

import pandas as pd
import numpy as np
import matplotlib.pyplot as plt

# ============================
#  CHL bias vs local solar time
# ============================

df = pd.read_parquet("data/CHLA_argo_profiles_plus_PACE.parquet")
df = df.dropna(subset=["CHLA_0_10"])

df_bias = df.copy()

# --- Ensure datetime ---
df_bias['TIME'] = pd.to_datetime(df_bias['TIME'], utc=True, errors='coerce')

# --- Basic cleaning: drop rows missing key fields ---
df_bias = df_bias.dropna(subset=['TIME', 'LONGITUDE', 'CHLA_0_10', 'pace_chlor_a'])

# --- Remove non-positive CHL (can't take log10 of these) ---
df_bias = df_bias[(df_bias['CHLA_0_10'] > 0) & (df_bias['pace_chlor_a'] > 0)]

# --- Compute log10 CHL and bias (PACE - Argo) ---
eps = 1e-6  # tiny offset for numerical safety, but we already filtered <=0
df_bias['log_chl_argo'] = np.log10(df_bias['CHLA_0_10'] + eps)
df_bias['log_chl_sat'] = np.log10(df_bias['pace_chlor_a'] + eps)
df_bias['bias'] = df_bias['log_chl_sat'] - df_bias['log_chl_argo']

# --- Compute local solar time (approx) ---
# longitude in degrees east; 15° = 1 hour offset from UTC
df_bias['solar_hour'] = (df_bias['TIME'].dt.hour + df_bias['LONGITUDE'] / 15.0) % 24

# Bin into integer solar hours (0–23)
df_bias['solar_hour_bin'] = df_bias['solar_hour'].astype(int)

# --- Group by local solar hour and compute stats ---
bias_by_solar = df_bias.groupby('solar_hour_bin')['bias'].agg(['mean', 'median', 'std', 'count'])

#print("Bias (log10, PACE - Argo) by *local solar hour*:")
#display(bias_by_solar)

# --- Plot mean bias vs local solar hour ---
plt.figure(figsize=(8, 4))
plt.plot(bias_by_solar.index, bias_by_solar['mean'], '-o')
plt.axhline(0, color='k', lw=1)
plt.xlabel('Local Solar Hour')
plt.ylabel('Mean log10 Bias (PACE - Argo)')
plt.title('log CHL Sat - log CHL Argo vs Local Solar Time (NPQ Signature)')
plt.grid(True)
plt.xticks(range(0, 24))
plt.tight_layout()
plt.show()

Look at correlation with Kd

Kd is correlated with chlor_a so this is a bit of a repeat of the first plot.

df = pd.read_parquet("data/CHLA_argo_profiles_plus_PACE.parquet")

df_bias = df.copy()

# --- Ensure datetime ---
df_bias['TIME'] = pd.to_datetime(df_bias['TIME'], utc=True, errors='coerce')

# --- Basic cleaning: drop rows missing key fields ---
df_bias = df_bias.dropna(subset=['TIME', 'LONGITUDE', 'CHLA_0_10', 'pace_chlor_a'])

# --- Remove non-positive CHL (can't take log10 of these) ---
df_bias = df_bias[(df_bias['CHLA_0_10'] > 0) & (df_bias['pace_chlor_a'] > 0)]

# --- Compute log10 CHL and bias (PACE - Argo) ---
eps = 1e-10  # tiny offset for numerical safety, but we already filtered <=0
df_bias['log_chl_argo'] = np.log10(df_bias['CHLA_0_10'] + eps)
df_bias['log_chl_sat'] = np.log10(df_bias['pace_chlor_a'] + eps)
df_bias['bias'] = df_bias['log_chl_sat'] - df_bias['log_chl_argo']

# --- Compute local solar time (approx) ---
# longitude in degrees east; 15° = 1 hour offset from UTC
df_bias['solar_hour'] = (df_bias['TIME'].dt.hour + df_bias['LONGITUDE'] / 15.0) % 24

# --- Remove mid day solar hour ---
df_bias = df_bias[~((df_bias['solar_hour'] > 8) & (df_bias['solar_hour'] < 16))]

# Scatter plot
plt.figure(figsize=(5, 5))
plt.scatter(df_bias['bias'], 1/df_bias['pace_Kd_490'], s=3, alpha=0.3)

plt.xlabel("bias (log10 pace - log10 argo)")
plt.ylabel("1/Kd (bigger = clearer)")
plt.title("satelitte is larger than argo in clearer water")
plt.tight_layout()
plt.show()
