py-rocket-geospatial-2

---

What is py-rocket-geospatial-2?

py-rocket-geospatial-2 is a Python–R geospatial Docker image for large-scale earth-science data analysis in JupyterHub environments.

It is designed for users working with large earth-observation datasets, especially cloud-native data, from organizations such as NOAA, NASA, and other public earth-science data providers. The image targets workflows common in cryoscience, oceanography, climate science, and remote sensing. It is optimized for:

• big-data, array-based analysis
• cloud object storage and distributed computing
• shared, multi-user JupyterHub deployments

---

py-rocket-geospatial-2 combines three ecosystems:

Python (Pangeo-style big-data stack)

• Based on the Pangeo notebook environment
• Designed for xarray/Dask-style workflows
• Extended with additional geospatial and scientific packages

R (Rocker-based geospatial environment)

• R installed via Rocker installation scripts
• RStudio and JupyterLab share the same R environment
• R runs independently of the conda Python environment

Desktop tools for earth science

• Linux desktop via VNC
• Pre-installed applications commonly used in earth-science workflows: QGIS, Panoply, CoastWatch Utilities

The image also includes Quarto, TeX Live, MyST, and JupyterBook for scientific publishing.

---

Runtime overview

• Python: 3.11
  • Conda environment notebook, activated on startup
• R: 4.5.x
  • Shared across RStudio and JupyterLab

---

Using

The image is designed to be used in JupyterHubs and you can use in your hub yaml with ghcr.io/nmfs-opensci/container-images/py-rocket-geospatial-2:latest but best practice is to pin to a specific tag.

You can also run on a computer with Docker installed with

docker pull ghcr.io/nmfs-opensci/container-images/py-rocket-geospatial-2:latest
docker run -it --rm -p 8888:8888 ghcr.io/nmfs-opensci/container-images/py-rocket-geospatial-2:latest

---

Image structure

• Base infrastructure (Jupyter, Dask, Python install, conda setup, R install, and user-experience configuration) lives in
  py-rocket-base

• py-rocket-geospatial-2 adds:

  • Python and R geospatial packages
  • Desktop applications (QGIS, CoastWatch Utilities, Panoply)

See the py-rocket-base documentation for base image design details.

---

Reproducibility and validation

This repository automatically maintains pinned and validated package lists:

• reproducibility/packages-python-pinned.yaml
• reproducibility/packages-r-pinned.R
• reproducibility/build.log

Pinned versions are extracted directly from the built image and validated against the requested package lists to support reproducibility and debugging.

---

CI/CD Workflow

Automated Build and Test Pipeline

The repository uses a streamlined CI/CD workflow that ensures quality before publishing Docker images:

Workflow: Build → Test → Push → Create Release PR (all in one job)

The main build-test-push job executes:

1. Build - Docker image is built and tagged (stays in runner’s Docker cache)
2. Test Python - Python notebook tests run against the built image
3. Test Packages - Package validation ensures all specified packages are installed
4. Push - Image is pushed to GHCR only if tests pass
5. Create Release PR - A separate job creates a pull request with pinned package versions

Design: The Docker image (~7GB compressed) stays in the build runner’s local Docker cache, avoiding artifact transfer overhead. Only small artifacts (test results, validation reports) are uploaded with 7-day retention.

Manual Workflow Triggers

You can manually trigger the workflow with options:

• Standard Build: Go to Actions → “Docker Image Build and Push” → Run workflow
  • Tests will run before pushing the image
• Skip Tests (Debugging): Run workflow with skip_tests: true
  • Use this option when debugging image build issues
  • Image builds and pushes immediately without running tests
  • ⚠️ Use with caution - only for debugging broken builds

Workflow Files

• .github/workflows/build-and-push.yml - Main workflow (build, test, push, release)
• .github/workflows/test-python.yml - Manual test trigger for existing images
• .github/workflows/pin-packages.yml - Manual package validation for existing images

Automatic Triggers

The workflow automatically runs when changes are pushed to main affecting:

• .github/actions/build-and-push/action.yml
• .github/workflows/build-and-push.yml
• Dockerfile
• conda-env/env-*.yml
• install.R
• apt.txt
• Desktop/**

---

Customization and derivative images

To customize py-rocket-geospatial-2

• edit the Python packages in conda-env/env-*.yml
• edit the R packages in install.R
• update the QGIS, CoastWatch Utilities, and Panoply installs in Dockerfile
• update the systems installs in `apt.txt

If changes affect core platform behavior, please open an issue in py-rocket-base

To create derivative images

1. You can create a derivative image using py-rocket-geospatial-2 as the base. This will add packages to the conda and R environments. For example

FROM ghcr.io/nmfs-opensci/container-images/py-rocket-geospatial-2:2026.02.08

USER root

COPY . /tmp/
RUN /pyrocket_scripts/install-conda-packages.sh /tmp/your-environment.yml || echo "install-conda-packages.sh failed" || true
RUN /pyrocket_scripts/install-r-packages.sh /tmp/install.R || echo "install-r-package.sh failed" || true
RUN rm -rf /tmp/*

USER ${NB_USER}
WORKDIR ${HOME}

1. You can use the https://github.com/nmfs-opensci/py-rocket-geospatial-2/Dockerfile as a template.

2. Making your derivative image build automatically in GitHub from your repo.

   • Copy .github/actions/build-and-push/action.yml to the same location in your repo
   • Copy .github/workflows/build-and-push.yml into your repo and edit the image-name.
   • Set up your repo to allow packages to be published to your location from your repo.

---

Provenance

This image was originally maintained under
https://github.com/nmfs-opensci/container-images

It now lives in its own dedicated repository as part of the NMFS OpenSci container ecosystem.
